1581052
Official DistributorSKU
PHX1581052
MPN
DC-B 6-HTC-M25-M25-M
Weight
0.249 kg
This product is Not Cancellable/Not Returnable
Series DC-B
DC-B 6-HTC-M25-M25-M - T box
DUPLICON, aluminum T-box, type B6, IP67 protection, 2 x M25 cable screw connection thread (without cable screw connection)
Technical Specifications
Product properties
| Housing type | Box mounting bases |
| Type | DC-B6 |
| Number of Positions | 0 |
| No. of cable outlets | 2 |
| Type of the screw connection | with M25 thread |
| Seal present | no |
| Protective cover | no |
| Cable outlet | lateral |
| Pg screw connection | none |
Connection data
| Connection Method | Screw connection |
Dimensions
| Width | 81 mm |
| Height | 72 mm |
| Length | 81 mm |
Material specifications
| Color | pearl gray |
| Material Housing | die-cast aluminum |
| Housing Material | die-cast aluminum |
| Impact strength | IK08 |
Mechanical data
| Type of the screw connection | with M25 thread |
| Locking Type | Pin |
Ambient conditions
| Degree of Protection | IP65 |
| Degree of Protection | IP66 |
| Degree of Protection | IP67 |
| Degree of Protection | IP65/IP66/IP67 |
| Impact strength | IK08 |
| Ambient Temperature (Operation) | -40 °C ... 125 °C |
| Ambient temperature (storage/transport) | -40 °C ... 125 °C |
Mounting
| Mounting Type | Screw mounting |
Accessories
Why Proax for Phoenix Contact 1581052?
Proax is an authorized distributor of Phoenix Contact 1581052 and one of Phoenix Contact's largest distributors in North America. Our highly skilled in-house technical team is ready to assist with any technical needs.
Have a question in mind? to help you get the right product as quickly as possible for your project. We're always here to help!
Short Lead Time
Highly Trained Staff
Live Chat
Technical Support
Local Inventory
60+ Years Experience
Additional Information
| Pack Size | 10 |
