2024 Spring Specials

Quarterly Special valid from April 1st - June 30th, 2024

Signal Conditioner

MINI Analog Pro

Safe isolation, conditioning, filtering, and amplification for analog signal processing
Configurable using software or DIP switches or both
Compatible with numerous analog signal combination inputs
Integrate field signals into industrial networks while also benefiting
from safe electrical isolation
Phoenix Contact 2902040
MINI MCR-2-UI-UI-PT - 3-way signal conditioner with plug-in connection technology and calibrated measuring range changeover, for the electrical isolation of unipolar and bipolar analog signals. Input/output configurable via DIP switch. push-in connection technology, standard configuration.
Phoenix Contact 2902037
MINI MCR-2-UI-UI - 3-way signal conditioner with plug-in connection technology and calibrated measuring range changeover for the electrical isolation of unipolar and bipolar analog signals. Input/output configurable via DIP switch. Screw connection technology, standard configuration.
Phoenix Contact 2905028
MINI MCR-2-UNI-UI-2UI-PT - Universally configurable 4-way signal duplicator, with plug-in connection technology for the electrical isolation and duplication of analog signals. Configurable via DIP switch or software. Push-in connection technology, standard configuration.
Phoenix Contact 2905026
MINI MCR-2-UNI-UI-2UI - Universally configurable 4-way signal duplicator, with plug-in connection technology for the electrical isolation and duplication of analog signals. Configurable via DIP switch or software. Screw connection technology, standard configuration.

Unmanaged Switches

FL 1000 and 1100 series

Requires minimal space thanks to very compact design
Gigabit versions with jumbo frames for high data throughput
Multiple approvals, including maritime and hazardous
Temperature range from: -40°C to +75°C
Metal body (base and DIN latch)
AC or DC input range; 9-32VDC or 18-30VAC input
Phoenix Contact 1085170
FL SWITCH 1005NT - Narrow Ethernet switch, wide temperature range five RJ45 ports with 10/100 Mbps on all ports, automatic data transmission speed detection, autocrossing function, and QoS
Phoenix Contact 1085165
FL SWITCH 1008NT - Narrow Ethernet switch, wide temperature range, eight RJ45 ports with 10/100 Mbps on all ports, automatic data transmission speed detection, autocrossing function, and QoS
Phoenix Contact 1343027
FL SWITCH 1024T - Ethernet switch, twenty-four RJ45 ports with 10/100 Mbps on all ports, automatic data transmission speed detection, autocrossing function, and QoS
Phoenix Contact 1085163
FL SWITCH 1105NT - Narrow Ethernet switch, wide temperature range, five RJ45 ports with 10/100/1000 Mbps on all ports, automatic data transmission speed detection, autocrossing function, and QoS
Phoenix Contact 1085162
FL SWITCH 1108NT - Narrow Ethernet switch, wide temperature range, eight RJ45 ports with 10/100/1000 Mbps on all ports, automatic data transmission speed detection, autocrossing function, and QoS
Phoenix Contact 1085115
FL SWITCH 1116T - Ethernet switch, sixteen RJ45 ports with 10/100/1000 Mbps on all ports, wide temperature range, automatic data transmission speed detection, autocrossing function, and QoS

M12 connectors with Push-Lock connection

Tool-free with direct plug-in

Tool-less connection of rigid and flexible conductors with and without ferrules
Intuitive conductor connection with color and numerical coding of the contact levers
High conductor pull-out forces with proven spring-cage technology
4-,5-pos. // A-, B-, D-, S-, T-, K-, L-coded
Shielded, unshielded - IP65, IP67
Male, female // straight, angled
Phoenix Contact 1424649
SACC-M12MS-5PL M - Connector, Universal, 5-position, unshielded, Plug straight M12, coding: A, Push-lock spring connection, knurl material: Zinc die-cast, nickel-plated, external cable diameter 4 mm ... 8 mm
Phoenix Contact 1424651
SACC-M12MR-5PL M - Connector, Universal, 5-position, unshielded, Plug angled M12, coding: A, Push-lock spring connection, knurl material: Zinc die-cast, nickel-plated, external cable diameter 4 mm ... 8 mm
Phoenix Contact 1424652
SACC-M12FS-5PL M - Connector, Universal, 5-position, unshielded, Socket straight M12, coding: A, Push-lock spring connection, knurl material: Zinc die-cast, nickel-plated, external cable diameter 4 mm ... 8 mm
Phoenix Contact 1424653
SACC-M12FR-5PL M - Connector, Universal, 5-position, unshielded, Socket angled M12, coding: A, Push-lock spring connection, knurl material: Zinc die-cast, nickel-plated, external cable diameter 4 mm ... 8 mm
Phoenix Contact 1424654
SACC-M12MR-4PL M - Connector, Universal, 4-position, unshielded, Plug angled M12, coding: A, Push-lock spring connection, knurl material: Zinc die-cast, nickel-plated, external cable diameter 4 mm ... 8 mm
Phoenix Contact 1424655
SACC-M12FS-4PL M - Connector, Universal, 4-position, unshielded, Socket straight M12, coding: A, Push-lock spring connection, knurl material: Zinc die-cast, nickel-plated, external cable diameter 4 mm ... 8 mm
Phoenix Contact 1424656
SACC-M12FR-4PL M - Connector, Universal, 4-position, unshielded, Socket angled M12, coding: A, Push-lock spring connection, knurl material: Zinc die-cast, nickel-plated, external cable diameter 4 mm ... 8 mm
Phoenix Contact 1424657
SACC-M12MS-4PL M - Connector, Universal, 4-position, unshielded, Plug straight M12, coding: A, Push-lock spring connection, knurl material: Zinc die-cast, nickel-plated, external cable diameter 4 mm ... 8 mm
Phoenix Contact 1424658
SACC-M12MS-5PL SH - Connector, Universal, 5-position, shielded, Plug straight M12, coding: A, Push-lock spring connection, knurl material: Zinc die-cast, nickel-plated, external cable diameter 4 mm ... 8 mm
Phoenix Contact 1424659
SACC-M12MR-5PL SH - Connector, Universal, 5-position, shielded, Plug angled M12, coding: A, Push-lock spring connection, knurl material: Zinc die-cast, nickel-plated, external cable diameter 4 mm ... 8 mm

FDX20 Fusion Splice Boxes and Fiber Patch Cords

High-speed, future-proof data transmission

Compact DIN-Rail mounting
Up to 12 duplex LC connections for more space in control cabinets
Reduce installation time with pre-assembled design for fusion splicing
Operating temperature range from -25°C to +70°C
OM4 fiber supports 10GBase-SX up to 550m run length
OM4 fiber supports 1000Base-SX to 1040m, 1000Base-LX to 600m
Phoenix Contact 1019712
FOC-FDX20-PP-LCD6-OM4-PT9 - Splice box, design: Rail-mountable module, degree of protection: IP20, material: Metal, connection method: Splicing, cable outlet: above and below, housing size: 1, color: gray, Ethernet
Phoenix Contact 1019708
FOC-FDX20-PP-LCQ6-OM4-PT9 - Splice box, design: Rail-mountable module, degree of protection: IP20, material: Metal, connection method: Splicing, cable outlet: above and below, housing size: 1, color: gray, Ethernet
Phoenix Contact 1115625
FOC-LC:PA-LC:PA-OM4:D01/1 - Multi-mode OM4 duplex jumper, LC-LC, UPC polishing, length 1 m

Power Supplies

TRIO POWER — TRIO3

Dynamic boost up to 150% for 5s
Supply and protection in one device due to the integrated multichannel device protection with IO-LINK
Group message contact and multicolor LED
Easy installation with Push-In connection and minimum installed depth of just 125 mm
Wide temperature range: -25°C ... +70°C, startup type tested: -40°C
Class 1 Div 2 approval
Phoenix Contact 1159037
TRIO3-PS/1AC/24DC/5 - Primary-switched power supply unit, TRIO POWER, Push-in connection, DIN rail mounting, input: 1-phase, output: 24 V DC / 5 A, adjustable from 24 V DC ... 28 V DC
Phoenix Contact 1159038
TRIO3-PS/1AC/24DC/10 - Primary-switched power supply unit, TRIO POWER, Push-in connection, DIN rail mounting, input: 1-phase, output: 24 V DC / 10 A, adjustable from 24 V DC ... 28 V DC
Phoenix Contact 1159039
TRIO3-PS/1AC/24DC/20 - Primary-switched power supply unit, TRIO POWER, Push-in connection, DIN rail mounting, input: 1-phase, output: 24 V DC / 20 A, adjustable from 24 V DC ... 28 V DC
Phoenix Contact 1159042
TRIO3-PS/3AC/24DC/10 - Primary-switched power supply unit, TRIO POWER, Push-in connection, DIN rail mounting, input: 3-phase, output: 24 V DC / 10 A, adjustable from 24 V DC ... 28 V DC
Phoenix Contact 1159044
TRIO3-PS/3AC/24DC/20 - Primary-switched power supply unit, TRIO POWER, Push-in connection, DIN rail mounting, input: 3-phase, output: 24 V DC / 20 A, adjustable from 24 V DC ... 28 V DC
Phoenix Contact 1159045
TRIO3-PS/3AC/24DC/40 - Primary-switched power supply unit, TRIO POWER, Push-in connection, DIN rail mounting, input: 3-phase, output: 24 V DC / 40 A, adjustable from 24 V DC ... 28 V DC
Phoenix Contact 1252696
TRIO3-PS/1AC/24DC/10/4C/IOL - Primary-switched power supply unit, TRIO POWER, Push-in connection, 4-channel electronic circuit breaker, IO-Link, DIN rail mounting, input: 1-phase, output: 24 V DC / 10 A, adjustable from 24 V DC ... 28 V DC
Phoenix Contact 1252697
TRIO3-PS/1AC/24DC/20/8C/IOL - Primary-switched power supply unit, TRIO POWER, Push-in connection, 8-channel electronic circuit breaker, IO-Link, DIN rail mounting, input: 1-phase, output: 24 V DC / 20 A, adjustable from 24 V DC ... 28 V DC

Cable ducts and Cable duct cutter

Mounting materials for control cabinets

Cover snaps on easily
Cover included
Single part number for cable duct and cover
2m length, matches Phoenix Contact 2m DIN rail product
Two score lines for easy removal of fingers and wall, no sharp edges
Phoenix Contact 3240188
CD 25X40 - Cable duct for installation and mounting in control cabinets, gray, comprising upper part and mounting base, width: 25 mm, height: 40 mm, length: 2000 mm
Phoenix Contact 3240191
CD 25X60 - Cable duct for installation and mounting in control cabinets, gray, comprising upper part and mounting base, width: 25 mm, height: 60 mm, length: 2000 mm
Phoenix Contact 3240197
CD 25X80 - Cable duct for installation and mounting in control cabinets, gray, comprising upper part and mounting base, width: 25 mm, height: 80 mm, length: 2000 mm
Phoenix Contact 3240283
CD 30X100 - Cable duct for installation and mounting in control cabinets, gray, comprising upper part and mounting base, width: 30 mm, height: 100 mm, length: 2000 mm
Phoenix Contact 3240189
CD 40X40 - Cable duct for installation and mounting in control cabinets, gray, comprising upper part and mounting base, width: 40 mm, height: 40 mm, length: 2000 mm
Phoenix Contact 3240192
CD 40X60 - Cable duct for installation and mounting in control cabinets, gray, comprising upper part and mounting base, width: 40 mm, height: 60 mm, length: 2000 mm
Phoenix Contact 3240198
CD 40X80 - Cable duct for installation and mounting in control cabinets, gray, comprising upper part and mounting base, width: 40 mm, height: 80 mm, length: 2000 mm
Phoenix Contact 3240294
CD 40X100 - Cable duct for installation and mounting in control cabinets, gray, comprising upper part and mounting base, width: 40 mm, height: 100 mm, length: 2000 mm
Phoenix Contact 3240199
CD 60X80 - Cable duct for installation and mounting in control cabinets, gray, comprising upper part and mounting base, width: 60 mm, height: 80 mm, length: 2000 mm
Phoenix Contact 3240263
CD 60X100 - Cable duct for installation and mounting in control cabinets, gray, comprising upper part and mounting base, width: 60 mm, height: 100 mm, length: 2000 mm
Phoenix Contact 1207569
PPS CD M - Cable duct cutter, for burr-free cutting cable ducts and their covers, can be used up to a width of 125 mm
Phoenix Contact 1212474
CUTFOX-CD - Cable duct cutter, for cutting plastic cable ducts, covers, and profiles, 45° limit stop also for bevel cuts, 75 mm cutting length

DIN rail with DIN rail cutter

The DIN rail portfolio includes various DIN rail standard dimensions such as the NS 35/7,5, NS 35/15, and NS 15 versions. It also includes galvanized and uncoated DIN rails. Perforated and unperforated DIN rails are also available. In addition to these DIN rails, the portfolio also includes G-type DIN rails.

Phoenix Contact 0801733
NS 35/ 7,5 PERF 2000MM - DIN rail perforated, Pack of 25 (50 m), acc. to EN 60715, material: Steel, galvanized, passivated with a thick layer, Standard profile, color: silver
Phoenix Contact 1207585
PPS BASIC I/M - Profile cutter, for cutting standard DIN rails to length, NS 15 / NS 35/7,5 / NS 35/15, and for cutting the NLS‑CU 3/10 neutral busbar to length, with inch/metric measuring rail
