2400180
Official DistributorSKU
PHX2400180
MPN
WATERWORX
Weight
0.081 kg
WATERWORX - Function block
WATERWORX includes function block libraries for PC Worx which supplement the control technology from Phoenix Contact with functions such as regulation or control of field devices in process automation for water and wastewater treatment. The function blocks can be downloaded.
- Minimized engineering costs for programming, thanks to ready-made function blocks
- Reduced maintenance effort, thanks to uniform programming of your system
- Industry-specific library for process automation in drinking water treatment and wastewater purification applications
- Easy integration of measurement and control technology using pre-programmed function blocks
- User-friendly function blocks, programs, and help
Technical Specifications
General
| Information regarding the system requirements | Note the individual properties and requirements of the devices. Should you have any questions, please contact the Support team directly or the relevant contact person in Sales. |
System properties
| Function block type | Communication |
| Function block type | Closed-loop control |
| Intended use for the software | Software library |
License information
| Type of license | License key for function blocks |
| Information regarding the type of license | Function block library can be used without license in demo mode for one week |
Functionality
| Basic Functions | Process automation in Water and Wastewater Treatment |
| Expanded functionality | Manufacturer-independent integration of industry-specific field devices |
| Expanded functionality | Storage of preset values |
| Expanded functionality | PROFINET, PROFIBUS, Modbus/TCP, Modbus/RTU, and HART supported |
| Expanded functionality | Integration of customary functions such as control of motors, pumps, fans, flaps, valves, and technical control applications |
| Supported controllers | ILC 1xx |
| Supported controllers | ILC 3xx |
| Supported controllers | RFC 47x |
| Supported controllers | AXC 1xxx, AXC 3xxx, PC WORX RT BASIC/SRT (without support of HART) |
System requirements
| Languages supported | German, English |
| Engineering tool | PC Worx |
| Software requirements | PC WORX Version 6.30 or later |
Accessories
SD FLASH 512MB APPLIC A - Program and configuration memory for extending the internal Flash memory, plug-in, 512 MB with license key for function block libraries. For licensed function blocks, please refer to the documentation.
AXC 1050 - Axio control for direct open-loop control of Axioline I/Os. With 2 Ethernet interfaces and programming capabilities according to IEC 61131-3. Complete with connector connector and labeling field.
ILC 151 ETH - The Inline controller offers the option of communicating via PROFINET and Modbus/TCP. Programming is carried out using PC Worx Express or PC Worx (IEC 61131-3).- ILC 151 ETH/XC - Inline controller for use under harsh ambient conditions, with Ethernet interface for coupling to other controllers and systems, with programming options according to IEC 61131-3, complete with connector and labeling field.
ILC 151 GSM/GPRS - Inline Controller with Ethernet interface and GSM modem for coupling to other controllers and systems, with programming options according to IEC 61131-3, complete with plug and labeling field.
The Inline controller offers the option of communicating via PROFINET and Modbus/TCP. Programming is carried out using PC Worx Express or PC Worx (IEC 61131-3).- ILC 191 ETH 2TX - The Inline controller offers the option of communicating via PROFINET and Modbus/TCP. Programming is carried out using PC Worx Express or PC Worx (IEC 61131-3).
ILC 350 PN - Inline Controller with PROFINET interface for coupling to other controllers and systems, with programming options according to IEC 61131-3, complete with plug and labeling field.
RFC 460R PN 3TX - High-availability Remote Field Controller with redundancy function, 3 x 10/100 Ethernet, PROFINET controller, IP20 protection, plug-in parameterization memory
RFC 470 PN 3TX, Remote Field Controller with 3x10/100 Ethernet, INTERBUS-Master, PROFINET-Controller, PROFINET device, IP20 degree of protection, pluggable parameterization memory
