Phoenix Contact 2906279
AllCircuit ProtectionProtectionSurge Protection
Phoenix ContactOfficial Distributor

By Phoenix Contact

SKU
MPN
VAL-US 60/O
Weight
0.125 kg
Series VAL-US

VAL-US 60/O - Type 2 surge protection device

Surge arresters consisting of base element and protective connector with high-capacity varistor, for mounting on NS 35/7.5, 1-channel

  • Rack-mount 2U panel applications
  • Plug-in direction parallel to the conductor axis
  • Versions with and without floating remote indication contact
  • DIN rail mounting
  • Accepts Type 1 and Type 2 VAL-MS plugs
  • Coding when protective plug is inserted for the first time
Technical Specifications

Product properties

Product familyVALVETRAB MS
IEC test classificationII
IEC test classificationT2
EN typeT2
TypeDIN rail module, two-section, divisible
Number of Positions1
Surge protection fault messageoptical

Insulation characteristics

Pollution degree2

Electrical properties

Nominal frequency fN50 Hz (60 Hz)

Connection data

Connection MethodScrew connection
Screw threadM5
Tightening torque3 Nm ... 4.5 Nm (UL)
Tightening torque27 lbf-in. ... 40 lbf-in. (UL)
Stripping length16 mm
Conductor cross section flexible min.1.5 mm²
Conductor cross section flexible max.25 mm²
Conductor cross section, rigid min.1.5 mm²
Conductor cross section, rigid max.35 mm²
Conductor cross section AWG15 ... 2
Conductor cross section AWG14 ... 2 (UL)
Connection MethodScrew connection
Screw threadM5
Tightening torque4.5 Nm
Tightening torque30 lbf-in. (UL)
Stripping length16 mm
Conductor cross section flexible min.1.5 mm²
Conductor cross section flexible max.25 mm²
Conductor cross section, rigid min.1.5 mm²
Conductor cross section, rigid max.35 mm²
Conductor cross section AWG15 ... 2
Conductor cross section AWG14 ... 2 (UL)

Dimensions

Width17.6 mm
Height77.1 mm
Depth89.2 mm

Material specifications

Colorblack (RAL 9005)
Flammability rating according to UL 94V0
Housing MaterialPBT

Protective circuit

Mode of protectionL-PEN
Mode of protection(L+) - (L-)
Mode of protection(L-) - PE
Mode of protection(L+) - PE
Direction of actionL-N / L-PEN
Nominal voltage UN60 V DC
Nominal voltage UN-48 V DC (RRH)
Nominal frequency fN50 Hz (60 Hz)
Maximum continuous voltage UC75 V AC
Maximum continuous voltage UC100 V DC
Maximum continuous operating voltage UC (L-N)75 V AC
Maximum continuous operating voltage UC (L-N)100 V DC
Maximum continuous operating voltage UC (L-PEN)75 V AC
Maximum continuous operating voltage UC (L-PEN)100 V DC
Rated load current IL80 A
Residual current IPE≤ 0.45 mA
Standby power consumption PC≤ 35.00 mVA
Nominal discharge current In (8/20) µs15 kA
Nominal discharge current In (8/20) µs (L-N)15 kA
Nominal discharge current In (8/20) µs (L-PEN)15 kA
Maximum discharge current Imax (8/20) µs40 kA
Maximum discharge current Imax (8/20) µs (L-N)40 kA
Maximum discharge current Imax (8/20) µs (L-PEN)40 kA
Short-circuit current rating ISCCR25 kA
Voltage protection level Up≤ 0.55 kV
Voltage protection level Up (L-N)≤ 0.55 kV
Voltage protection level Up (L-PEN)≤ 0.55 kV
Residual voltage Ures≤ 0.55 kV (at In)
Residual voltage Ures≤ 0.425 kV (at 10 kA)
Residual voltage Ures≤ 0.325 kV (at 5 kA)
Residual voltage Ures≤ 0.275 kV (at 3 kA)
TOV behavior at UT100 V AC (5 s / withstand mode)
TOV behavior at UT (L-N)100 V AC (5 s / withstand mode)
TOV behavior at UT (L-PEN)100 V AC (5 s / withstand mode)
Response time tA≤ 25 ns
Response time tA (L-N)≤ 25 ns
Response time tA (L-PEN)≤ 25 ns
Max. backup fuse with V-type through wiring80 A AC (gG)
Max. backup fuse with branch wiring125 A AC (gG)

Ambient conditions

Degree of ProtectionIP20 (only when all terminal points are used)
Degree of ProtectionIP20
Ambient Temperature (Operation)-40 °C ... 80 °C
Ambient temperature (storage/transport)-40 °C ... 80 °C
Altitudemax. 2000 m
Permissible humidity (operation)5 % ... 95 %
Shock (operation)25g (Half-sine / 11 ms / 3x ±X, ±Y, ±Z)
Vibration (Operation)5g (10 ... 500 Hz / 2.5 h / X, Y, Z)

UL specifications

Maximum continuous operating voltage MCOV75 V AC
Maximum continuous operating voltage MCOV (L-N)75 V AC
Maximum continuous operating voltage MCOV (L-G)75 V AC
Maximum continuous operating voltage MCOV (L+) - (L-)100 V DC
Maximum continuous operating voltage MCOV (L+/L-) - G100 V DC
Voltage protection rating VPR500 V
Voltage protection rating VPR (L-N)0.5 kV
Voltage protection rating VPR (L+) - (L-)0.33 kV
Voltage protection rating VPR (L+/L-) -G0.33 kV
Nominal discharge current In10 kA
Nominal discharge current In (L-N)10 kA
Nominal discharge current In (L+) - (L-)10 kA
Nominal discharge current In (L+/L-) - G10 kA
Mode of protectionL-L
Mode of protectionL-G
Mode of protection(L+) - (L-)
Mode of protection(L+) - G
Mode of protection(L-) - G
Nominal Voltage60 V DC
Power distribution systemSingle phase
Measured limiting voltage MLV630 V
Measured limiting voltage MLV (L-N)630 V
SPD Type4CA

UL indicator/remote signaling

Operating Voltage125 V AC
AC operating current1 A AC

UL connection data

Tightening torque30 lbf-in.
Conductor cross section AWG14 ... 2

Air clearances and creepage distances

Standards/regulationsEN 61643-11 / UL 840

Mounting

Mounting TypeDIN rail: 35 mm
