1587616
Official DistributorSKU
PHX1587616
MPN
Q 0,75/3LF/9-M16-FLANSCH
Weight
0.007 kg
Series Q
Q 0,75/3LF/9-M16-FLANSCH - Flange
QUICKON panel feed-through, PPC AG
Technical Specifications
Connection technology
| Connection method On the field side | IDC connection |
| Frequency of connections between conductors of the same cross section | 10 |
Conductor connection
| Conductor cross section flexibel | 0.34 mm² ... 0.75 mm² |
Cable/line
| Structure of individual litz in acc. with VDE 0295 / smallest wire diameter | Class 2-6 // 0.34 mm²: 0.1 mm; 0.5 - 0.75 mm²: 0.15 mm |
Why Proax for Phoenix Contact 1587616?
Proax is an authorized distributor of Phoenix Contact 1587616 and one of Phoenix Contact's largest distributors in North America. Our highly skilled in-house technical team is ready to assist with any technical needs.
Have a question in mind? to help you get the right product as quickly as possible for your project. We're always here to help!
Short Lead Time
Highly Trained Staff
Live Chat
Technical Support
Local Inventory
60+ Years Experience
Additional Information
| Pack Size | 50 |
