Technical Specifications
Additional Information
| ABB Type Designation | 2HP,3490RPM,3PH,60HZ,143TC,3526M,TE |
| Ambient Temperature | 40 °C |
| Bearing | 6205 |
| Bearing | Ball |
| Bearing NDE | 6203 |
| Bearing NDE | Ball |
| Brake Present | No |
| Brand / Label | Baldor-Reliance |
| Catalog Number | VEM3555T |
| Certification Agency | CSA |
| Certification Agency | CSA EEV |
| Certification Agency | UR |
| Country of Origin | United States (US) |
| Customs tariff number | 85015220 |
| Dimension Diagram | 35LYAA003 |
| Drive End Flange Type | C-Face |
| Duty Time | 60 Min |
| Efficiency Level | 2015 Small Motor Standard |
| Efficiency Level | IE3 |
| Efficiency Level | Premium Efficiency (NEMA 12-12) |
| Enclosure Type | TEFC |
| ETIM 7 | EC001851 - Electric motor |
| Frame Material | Steel |
| Frame Size | 143 |
| Frequency (f) | 60 Hz |
| Global Commercial Alias | VEM3555T |
| Gross Volume | 2110.969 in³ |
| Gross Weight | 18.597 kg |
| IDEA Granular Category Code (IGCC) | 1325 >> General purpose motor AC |
| Insulation Class | F |
| Invoice Description | 2HP,3490RPM,3PH,60HZ,143TC,3526M,TEFC,F1 |
| Made to Order | No |
| Medium Description | General Purpose 3PH Enclosed, 2 HP, 3600 RPM, Frame Size 143Tc, C-Face Mounting, 3 Phase, TEFC Enclosure, 208-230/460 V, 60 Hz (VEM3 |
| Minimum Order Quantity | 1 piece |
Additional Information
| Motor Base Type | Footless |
| Motor Frame Size | 143TC |
| Motor Frame Suffix | TC |
| Mounting Orientation | Horizontal |
| Mounting Position | F1 |
| NEMA Design Code | B |
| Number of phases | 3 |
| Number of Poles | 2 |
| Number of Poles (High) | 2 |
| Number of Speeds | Single Speed |
| Order Multiple | 1 piece |
| Output Power | 2 Hp |
| Product Net Depth / Length | 16.5 in |
| Product Net Height | 11.125 in |
| Product Net Weight | 18.597 kg |
| Product Net Width | 11.5 in |
| Product type | Undefined |
| Quote Only | No |
| Selling Unit of Measure | piece |
| Service Factor | 1.15 |
| Shaft Diameter | 0.875 in |
| Short Description | 2 HP, 3600 RPM, Frame Size 143Tc, C-Face, 3 PH, TEFC, 208-230/460 V |
| Standards | NEMA |
| Starting of Motor | Direct On Line |
| Stocked At (Warehouses) | China |
| Stocked At (Warehouses) | Alabama, United States |
| Stocked At (Warehouses) | Alaska, United States |
| Synchronous Speed (vsyn) | 3600 r/min |
| Type of Duty | Continuous |
| UNSPSC | 26101112 |
| Voltage Rating | 208 V |
| Voltage Rating | 230 V |
| Voltage Rating | 460 V |
