KS Plastic enclosure, WHD: 500x500x300 mm, Fibreglass-reinforced unsaturated polyester, with mounting plate, with door, viewing window
Supply includes
Housing with hinged door, of all-round solid construction, 3 mm double-bit lock
Mounting plate
Twin seal on the top and bottom edges of the door as integral rain protection strip
Press-fitted C sections at the sides for infinitely variable mounting plate depth adjustment
Viewing window in the door
Dimensions
| Width | 500 mm |
| Height | 500 mm |
| Depth | 300 mm |
Lock
| Lock version | Cam |
| Number locks | 2 |
| Lock Insert | 3 mm double-bit |
Material
| Housing and door | Fiberglass-reinforced unsaturated polyester |
| Door | All-round foamed-in PU seal |
| Mounting plate | Carbon steel |
| Viewing window | Glazed acrylic, 3.0 mm with all-round rubber cable clamp strip |
Mounting plate
| Width | 417 mm |
| Height | 450 mm |
Surface finish
| Housing and door | Dyed plastic with no after-treatment |
| Mounting plate | Zinc-plated |
| Version | with viewing window |
| Color | Similar to RAL 7035 |
| Protection category NEMA | NEMA 12 |
| Protection category IP to EN 60 529 | IP 56 |
| IK code | IK08 |
| Material thickness – mounting plate | 2.5 mm |
| Number of doors | 1 |
| Interchangeable door catch | Yes |
| No. of locks | 2 |
| With viewing window | Yes |
| Note | Under the influence of long-term UV radiation (sunlight) in conjunction with wind and rain, the surface finish may become visually impaired. This does not affect the protection of the installed electrical components in any way. If the enclosures cannot be protected from UV radiation, we recommend that they should be painted with a PUR paint. Permissible ambient temperature -30 °C...+75 °C. |
| Base material | Plastic |
| Weight/packaging unit | 13.4 kg |
| Customs tariff number | 94037000 |
| EAN | 4028177526730 |
| ETIM 7.0 | EC000261 |
| ECLASS 8.0 | 27180101 |
