Technical Specifications
Technical
| Standards | IEC/EN 60947-1 |
| Sub-Function | Space for auxiliary contatct |
| Suitable for | S200 |
| Suitable for | F200 |
| Suitable for | DDA200 |
| Suitable for | S-ARC1 |
| Suitable for Product Class | 2-pole devices + auxiliary contact |
| Rated Operational Voltage | 230 / 400 V AC |
| Rated Operational Voltage | Maximum 690 V |
| Rated Short-time Withstand Current Low Voltage (Icw) | 25 kA |
| Rated Uninterrupted Current (Iu) | 63 A |
| Rated Frequency (f) | 50 / 60 Hz |
| Rated Frequency (f) | DC |
| Pitch | 44729.0 |
| Number of Poles | 48 |
| Number of phases | 2 |
| Number of Mountable Devices | 24 |
| Number of Terminals (Nterm) | 48 |
| Overvoltage category | III |
| Accessory Type | Busbar |
| Connection Type | Pin |
| Housing Material | Light grey, RAL 7035 |
| Options Provided | H |
| Mounting Position | any |
| RAL Number | RAL 7035 - Light Grey |
| Color | grey |
| Rated Cross-Section | 10 mm² |
Dimensions
| Width in Number of Modular Spacings | 60 |
| Product Net Width | 14.8 mm |
| Product Net Height | 29 mm |
| Product Net Depth / Length | 1046 mm |
| Product Net Weight | 0.354 kg |
Installation
| Instructions and Manuals | 2CSC400002D0208 |
Why Proax for ABB PS2/48H?
Proax is an authorized distributor of ABB PS2/48H and one of ABB's largest distributors in North America. Our highly skilled in-house technical team is ready to assist with any technical needs.
Have a question in mind? to help you get the right product as quickly as possible for your project. We're always here to help!
Short Lead Time
Highly Trained Staff
Live Chat
Technical Support
Local Inventory
60+ Years Experience
Additional Information
| Alternate Names | PS248H |
| Pack Size | 1 |
