ADAM-4561/4562 allows PC users to connect a serial device to a system that use a USB interface. To attach the ADAM-4561/4562 to a PC, you don’t need to open the chassis or power down your PC. Instantly get one or two extra high-speed RS-232/422/485 ports. The power is derived from the USB port, so there are no power adapters to deal with. Thismakes the ADAM-4561/4562 especially suitable for modems, printers, POS systems and industrial control devices.
Features
- Power from the USB port
- Hot swap function supported
- Isolation protection 3000 VDC provided
- Automatic RS-485 data flow control
- Transmission speed up to 115.2 kbps
Documents
Technical Specifications
Communications
| Converter/Repeater | USB to RS-232/422/485 |
Environment
| Isolation Voltage | 3,000 VDC |
| Operating Temperature | -10~70 °C (14~158 °F) |
General
| Connectors | 1 x USB-type A, 1 x 10-pin plug-in screw terminal |
Power Requirements
| Input Voltage | Powered by USB port |
Serial Communication
| Baud Rate (bps) | 75 bps~115.2 kbps |
