ADAM-4571 and ADAM-4571L are fast and cost effective data gateways between serial and Ethernet interfaces. The units also bring the advantages of remote management and dataaccessibility to RS-232/422/485 devices. The transmission speed of the units is up to 230 kbps, meeting the demands for high-speed data exchanges. In addition, you can useWindows utility to configure ADAM-4571 and ADAM-4571L without further programming. The units not only protect your current hardware investment but also ensure future networkexpandability. Since the protocol conversion is transparent, all your existing devices can be seamlessly integrated with an Ethernet network. Therefore, ADAM-4571 and ADAM-4571Lcan be used in security systems, factory automation, SCADA, transportation and more. ADAM-4571 and ADAM4571L link both your existing human-machine interface(HMI) PC andyour RS-232/422/485 devices with Ethernet cables.ADAM-4571 and ADAM-4571L come with a Windows configuration and port-mapping utility. The configuration tool can auto-detect all Ethernet Data Gateway devices on the localnetwork, and let you adjust all settings. The port mapping utility helps you to setup up COM ports for Windows NT/2000/XP platform. This helps you configure all ports to meetyour needs.
Features
- Supports RS-232 serial communication
- Supports baud rate up to 921.6 kbps
- Provides COM port redirection (Virtual COM) mode
- Allows a max. of 5 hosts to access one serial port
- Built-in 15 KV ESD protection for all serial signals
- Provides 10/100 Mbps auto-sensing Ethernet port
- Supports auto re-connection function
- Supports Windows 2000/XP/Vista drivers
- Supports remote update firmware
Documents
Technical Specifications
Certification
| EMC | CE, FCC |
| EMI | EN 55011/ EN 55032 Class A, EN 61000-6-4, FCC Part 15 Subpart B Class A |
| EMS | EN 61000-4-2 (Level 2), EN 61000-4-3 (Level 2), EN 61000-4-4 (Level 2), EN 61000-4-5 (Level 2), EN 61000-4-6 (Level 2), EN 61000-4-8 (Level 2), EN55024 |
| Freefall | NA |
Environment
| Humidity (Operating Range) | 5~95% RH |
| Temperature (Min. Operating) | -10°C (14°F) |
| Temperature (Max. Operating) | 60°C (140°F) |
| Temperature (Operating Range) | -10 ~ 60°C (14 ~ 140°F) |
| Temperature (Storage Range) | -20 ~ 80°C (-4 ~ 176°F) |
Ethernet Communication
| RJ-45 Port Connector Type | RJ-45 |
| Ethernet Standard | IEEE 802.3 , 802.3u |
| RJ-45 Port Number | 1 |
| RJ-45 Transmission Speed | 10/100 Mbps |
Mechanism
| Dimensions (W x H x D) | 70 x 112 x 25 mm |
| Enclosure (Plastic) | Yes |
| IP Rating | IP30 |
| Mounting (DIN-rail) | Yes |
| Mounting (Wall) | Yes |
| Weight | 125 g |
Power
| Power consumption | 2.5W |
| Power Input (DC) | 10 ~ 30 VDC |
| Power Operating Current | 0.3A @ 12 V |
Serial Communication
| Serial Port Connector Type | RJ48 |
| Serial Port Number | 2 |
| RS-232 | Yes |
| Baud Rate | 50 ~ 921.6 Kbps |
Software
| Configuration | Windows utility, Web Browser |
| Driver | Windows XP/7/8.1/10, Windows Server 2003/2008/2012/2016/2019, and Linux |
| Operation Mode | Virtual COM, TCP/UDP server TCP/UDP client |
Warranty
| Warranty Period | 5 years |
Why Proax for Advantech ADAM-4570L-DE?
Proax is the authorized distributor of Advantech ADAM-4570L-DE. Our highly skilled in-house technical team is ready to assist with any technical needs.
Have a question in mind? to help you get the right product as quickly as possible for your project. We're always here to help!
Short Lead Time
Highly Trained Staff
Live Chat
Technical Support
Local Inventory
60+ Years Experience
Additional Information
| Alternate Names | ADAM4570LDE |
| Pack Size | 1 |
