Series CK3M Laser Control Module
Laser Interface Unit for CK3M, SL2-100 Protocol, Laser PWM output
Documents
CK3M Laser Control Module
High-speed Laser On/Off and multi-head configuration for ultra-high-speed and high precision processing.
When used in conjunction with advanced actuators, encoders, and precision mechanisms, the CK3MLSR enables a wide variety of applications where both speed and accuracy are required.
Features
- Laser ON/OFF independent of control cycle of the controller
- Synchronization between units for multi-head processing with less head misalignment
- Supports XY2-100 and SL2-100, standard protocols for Galvo scanners
- Galvo mirror control with resolution of up to 20 bits
- Mirror control using up to 3 channels (X, Y, and Z axes)
- CK3W-GC in combination with CK3W-AX and CK3W-ECS for high-speed, on-the-fly laser processing
Technical Specifications
| Axis capacity | 1 |
| Output Type | PWM output |
| Mounting | DIN Rail |
Why Proax for Omron CK3W-GC2100?
Proax is an authorized distributor of Omron CK3W-GC2100. We are Omron’s largest distributor in Canada. Our highly skilled in-house technical team is ready to assist with any technical needs.
Have a question in mind? to help you get the right product as quickly as possible for your project. We're always here to help!
Short Lead Time
Highly Trained Staff
Live Chat
Technical Support
Local Inventory
60+ Years Experience
Additional Information
| Alternate Names | CK3WGC2100 |
| Pack Size | 1 |
