3240262
Official DistributorSKU
PHX3240262
MPN
NS 30/15 PERF 2000MM VPE 10
Weight
1.4 kg
This item is ineligible for free shipping due to its size/weight.
NS 30/15 PERF 2000MM VPE 10 - DIN rail perforated
DIN rail perforated, Pack of 10 (20 m), similar to EN 60715, material: Steel, galvanized, C profile
- The cable clamps provide strain relief
- The halogen-free plastic troughs have been designed to be perfectly secure while simultaneously protecting the conductors
- Individual or bundled cables with a diameter of up to 64 mm can be installed safely and easily
Technical Specifications
Dimensions
| Width | 30 mm |
| Hole width | 15 mm |
| Height | 2000 mm |
| Hole height | 6.2 mm |
| Depth | 15 mm |
| Length | 2000 mm |
| Drill hole spacing | 25 mm |
Material specifications
| Material | Steel |
| Coating | galvanized |
Standards and Regulations
| Connection in acc. with standard | IEC / EN |
| Tests | similar to EN 60715 |
Why Proax for Phoenix Contact 3240262?
Proax is an authorized distributor of Phoenix Contact 3240262 and one of Phoenix Contact's largest distributors in North America. Our highly skilled in-house technical team is ready to assist with any technical needs.
Have a question in mind? to help you get the right product as quickly as possible for your project. We're always here to help!
Short Lead Time
Highly Trained Staff
Live Chat
Technical Support
Local Inventory
60+ Years Experience
Additional Information
| Pack Size | 1 |
