1SAL100546R9906
Weight
1 kg
The MP0CAE3 is a surge suppressor diode for contactor coils. Designed to reduce the maximum overvoltage peak value and to limit or even completely eliminate the high pre-damping voltage frequencies for a rated control circuit voltage between 6 ... 240 V. The surge suppressor is simply plugged onto the front of all MC1, MC2 and MCR DC operated variants.
Technical Specifications
Dimensions
| Product Net Width | 9 mm |
| Product Net Height | 18 mm |
| Product Net Depth / Length | 31 mm |
| Product Net Weight | 0.006 kg |
Technical
| Rated Frequency (f) | Control Circuit DC |
| Rated Insulation Voltage (Ui) | 750 V |
| Degree of Protection | IP20 |
| Standards | IEC/EN 60947-1 |
| Standards | IEC/EN 60947-4-1 |
| Standards | UL 60947-1 |
| Standards | UL 60947-4-1 |
| Rated Control Circuit Voltage (Uc) | DC Operation 6 ... 240 V DC |
| Suitable for | MC1 |
| Suitable for | MC2 |
| Suitable for | MCR DC operated |
| Suitable for Product Class | Mini Contactors |
Why Proax for ABB MP0CAE3?
Proax is an authorized distributor of ABB MP0CAE3 and one of ABB's largest distributors in North America. Our highly skilled in-house technical team is ready to assist with any technical needs.
Have a question in mind? to help you get the right product as quickly as possible for your project. We're always here to help!
Short Lead Time
Highly Trained Staff
Live Chat
Technical Support
Local Inventory
60+ Years Experience
Additional Information
| Pack Size | 1 |
