MS116-6.3
Official DistributorBy ABB
SKU
ABBMS11663
MPN
MS116-6.3
3-pole manual motor protection circuit breaker (MMP) with adjustable thermal setting range 4.0–6.3 A for three-phase motor protection. Rated up to 690 V AC with 2.2 kW at 400 V (AC-3), screw terminals, DIN-rail mount (TH35), and ON/OFF position indication. High short-circuit capacity up to Icu 75 kA at 400 V (Ics 50 kA). IP20 housing (IP10 at terminals); compliant with IEC/EN 60947 and UL 60947.
Documents
Technical Specifications
Supplier Information - USINY
| Lead Time | 28 day |
| Made to Order | No |
| Product Sales Status | Inactive |
| Quote Only | No |
| Replacement Part ID | 1SAM250000R1009 |
| Warranty Return | Product under warranty must be returned |
Additional Information
| ABB Type Designation | - |
| Country or Territory of Origin | United States |
| Customs tariff number | 8536504000 |
| Frame Size | Low_Voltage_Products |
| Gross Weight | 0.15 kg |
| Invoice Description | 3P MMP 4.0-6.3A RANGE |
| Made to Order | No |
| Minimum Order Quantity | 0 EA |
| Order Multiple | 0 EA |
| Part Type | New |
| Product Name | - |
| Product Net Weight | 0 kg |
| Product type | Low_Voltage_Products |
| Quote Only | No |
| Replacement Product ID (NEW) | 1SAM250000R1009 |
| Selling Unit of Measure | each |
| Temperature Class Default | -- |
| Two Speed Motor | No |
Why Proax for ABB MS116-6.3?
Proax is an authorized distributor of ABB MS116-6.3 and one of ABB's largest distributors in North America. Our highly skilled in-house technical team is ready to assist with any technical needs.
Have a question in mind? to help you get the right product as quickly as possible for your project. We're always here to help!
Short Lead Time
Highly Trained Staff
Live Chat
Technical Support
Local Inventory
60+ Years Experience
Additional Information
| Alternate Names | MS11663 |
| Pack Size | 1 |
