Looking for reliable industrial power supplies? Phoenix Contact QUINT POWER series delivers superior system availability through advanced functionality and comprehensive monitoring capabilities. These high-performance power supplies, including our popular phoenix contact quint power supply 24vdc 20a, combine preventive monitoring with powerful reserves, making them the ideal choice for demanding industrial applications.
Why Choose Phoenix Contact QUINT POWER?
The QUINT POWER series stands out in industrial power supply solutions through its combination of innovative features and robust reliability. Our phoenix quint power supply 24vdc 20a provides an excellent example of these capabilities, offering reliable performance for demanding applications.
Superior System Protection
QUINT POWER's Selective Fuse Breaking (SFB) Technology offers unmatched circuit protection. This innovative feature selectively trips standard miniature circuit breakers while maintaining power to parallel-connected loads, ensuring your critical systems stay operational. The phoenix contact quint-ps/1ac/24dc/10 demonstrates this capability perfectly in medium-sized industrial applications.
Preventive Monitoring
Stay ahead of potential issues with advanced preventive function monitoring. The phoenix contact quint power supply 24vdc 5 includes sophisticated monitoring systems that detect and report critical operating states before failures occur, allowing for proactive maintenance.
Advanced Performance Features
Powerful Boost Capabilities
The QUINT POWER series offers two essential power boost features for demanding applications. The static boost provides up to 125% sustained power output, perfect for system expansion needs. For handling challenging startup loads, the dynamic boost delivers up to 200% power for 5 seconds. The phoenix contact power supply 24vdc 40a exemplifies these capabilities in high-power applications.
| QUINT POWER >100 W | QUINT POWER <100 W | |
|---|---|---|
| SFB Technology | ✓ | ✗ |
| Preventive function monitoring | ✓ | ✓ |
| Can be ordered preconfigured | ✓ | ✗ |
| Choice between Push-in or screw connection | ✗ | ✓ |
| Static boost power reserve | ✓ | ✓ |
| Dynamic boost power reserve | ✓ | ✓ |
| Integrated gas discharge tube | ✓ | ✗ |
| Shallow device depth | ✓ | ✓ |
| Robust design | ✓ | ✓ |
| High efficiency | ✓ | ✓ |
Industrial-Grade Construction
Built for the toughest industrial environments, QUINT POWER supplies feature robust metal housing designed to operate across temperatures from -40°C to +70°C. The integrated gas discharge tube and extended mains failure buffer time exceeding 20ms ensure consistent performance, while high electromagnetic immunity protects against industrial interference.
See QUINT POWER in Action
Watch as we demonstrate these powerful features in real-world applications, showing how QUINT POWER supplies deliver superior performance across various industrial scenarios.
Flexible Integration Options
Communication Capabilities
QUINT POWER supplies integrate seamlessly with modern industrial systems through IO-Link direct connection and CAPAROC circuit breaker system integration. They support major industrial protocols including PROFINET, EtherNet/IP, EtherCAT, and Modbus, making them versatile additions to any industrial network.
Installation Flexibility
The QUINT4-PS/1AC/24DC/3.8/SC and other models in the series offer flexible installation options with both push-in and screw connection technology. DIN rail mounting comes standard, and configurable parameters allow for customization to specific application needs.
Complete System Monitoring
The QUINT POWER series provides comprehensive operating data transparency from AC input to DC output. Real-time performance monitoring enables preventive maintenance and seamless integration into control systems, significantly enhancing overall system reliability.
Safety and Certification
For applications requiring the highest safety standards, select QUINT POWER models offer SIL 3 compliance (IEC 61508) and redundant configuration options. The Plus versions provide enhanced safety features for critical applications where reliability is paramount.
Featured Products
QUINT4-PS/1AC/24DC/5
- A compact power supply with advanced preventive monitoring to detect critical operating states and ensure proactive maintenance.
QUINT4-PS/1AC/24DC/10
- Ideal for medium-sized applications, this model features Selective Fuse Breaking (SFB) technology for superior circuit protection.
QUINT4-PS/1AC/24DC/20
- A reliable and versatile power supply offering robust performance for demanding industrial environments.
Additional QUINT POWER Products to Explore
| Name | Part Number | Description |
|---|---|---|
| QUINT4-PS/1AC/24DC/10 - Power supply unit | 2904601 | Primary-switched QUINT POWER power supply with adjustable output characteristic curve, SFB technology, and NFC interface. Input: 1-phase; Output: 24 V DC / 10 A. |
| QUINT4-PS/1AC/24DC/20 - Power supply unit | 2904602 | Primary-switched QUINT POWER power supply featuring SFB technology, NFC interface, and adjustable output characteristic curve. Input: 1-phase; Output: 24 V DC / 20 A. |
| QUINT4-PS/1AC/24DC/5 - Power supply unit | 2904600 | Primary-switched QUINT POWER power supply with SFB technology, NFC interface, and customizable output characteristic curve. Input: 1-phase; Output: 24 V DC / 5 A. |
| QUINT4-PS/1AC/24DC/40 - Power supply unit | 2904603 | High-capacity QUINT POWER power supply with SFB technology, NFC interface, and adjustable output characteristic curve. Input: 1-phase; Output: 24 V DC / 40 A. |
| QUINT4-PS/3AC/24DC/20 - Power supply unit | 2904622 | Three-phase QUINT POWER power supply featuring SFB technology, NFC interface, and adjustable output characteristic curve. Input: 3-phase; Output: 24 V DC / 20 A. |
| QUINT4-PS/1AC/24DC/3.8/SC - Power supply unit | 2904599 | Primary-switched QUINT POWER power supply with screw connection, dynamic boost for heavy loads, and preventive function monitoring. Input: 1-phase; Output: 24 V DC / 3.8 A. |
| QUINT4-PS/12-24DC/24DC/2.5/SC - DC/DC converter | 1066718 | Primary-switched QUINT POWER DC/DC converter with screw connection, offering easy system expansion and preventive function monitoring. Input: 12-24 V DC; Output: 24 V DC / 2.5 A. |
| QUINT4-PS/1AC/12DC/2.5/PT - Power supply unit | 2904605 | Primary-switched QUINT POWER power supply with Push-in connection, dynamic boost for heavy loads, and space-saving design. Input: 1-phase; Output: 12 V DC / 2.5 A. |
| QUINT4-PS/12-24DC/24DC/1.3/SC - DC/DC converter | 1066703 | Primary-switched QUINT POWER DC/DC converter with screw connection, providing reliable heavy load startup and preventive function monitoring. Input: 12-24 V DC; Output: 24 V DC / 1.3 A. |
| QUINT4-PS/24DC/12DC/8/PT - DC/DC converter | 2910122 | Primary-switched QUINT POWER DC/DC converter with Push-in connection, SFB technology, and comprehensive signaling. Input: 24 V DC; Output: 12 V DC / 8 A. |
Phoenix Contact QUINT POWER supplies represent the pinnacle of industrial power supply technology, offering unmatched reliability and functionality. Their combination of advanced protection features, monitoring capabilities, and robust construction makes them the ideal choice for ensuring continuous operation in critical industrial applications. Browse our complete selection of industrial power supplies.
Contact our power supply experts today to find the perfect QUINT POWER solution for your application.
