||Published May 1, 2025|4 MIN READ

M12 Cable Material Selection Guide: PUR vs. PVC vs. TPE

M12 Cables have become the industry standard for sensor/actuator connectivity in industrial automation environments. When selecting the right M12 cable for your application, the jacket material is one of the most critical factors that will determine performance, durability, and reliability. This guide compares the three most common M12 cable jacket materials: PUR (Polyurethane), PVC (Polyvinyl Chloride), and TPE (Thermoplastic Elastomer).

Why Material Selection Matters

The right cable jacket material can mean the difference between a reliable connection that lasts for years and frequent cable failures resulting in costly downtime. In fact, according to industry research, up to 70% of field failures in industrial networks are related to cabling issues. By understanding the properties of different materials and making informed selections, you can significantly improve your system's reliability.

Quick Comparison: PUR vs. PVC vs. TPE

Property PVC PUR TPE
FlexibilityModerateHighVery High
Abrasion ResistanceGoodExcellentGood
Chemical ResistanceGood (acids/alkalis)Excellent (oils/chemicals)Excellent
Oil ResistanceModerateExcellentExcellent
UV/Weather ResistanceModerateExcellentExcellent
Temperature Range (°C)-25 to 70-40 to 80-50 to 125
Flame RetardancyGoodGoodExcellent
Flex LifeModerateHighVery High
Environmental ImpactContains halogensHalogen-free, recyclableNon-toxic, recyclable
Relative CostLowModerate to HighHigh
← Scroll horizontally to view more →

PVC (Polyvinyl Chloride)

phoenix contact PVC (Polyvinyl Chloride) m12 cables

Best for: General-purpose, static, and cost-sensitive applications

Advantages:

  • Economical solution for basic industrial applications
  • Good resistance to common cleaning chemicals and moisture
  • Rigid sheathing provides protection in washdown environments
  • Ideal for fixed installations with minimal movement

Limitations:

  • Less flexible than alternatives, especially in cold temperatures
  • Lower resistance to oils and abrasion compared to PUR or TPE
  • Contains halogens that can release toxic fumes when burned

Typical Applications:

  • General factory automation
  • Fixed sensor installations
  • Indoor control panels
  • Budget-conscious projects

Phoenix Contact PVC M12 Cables

Part Number Cable Length Connector Type Connector Orientation Sheath Material
1415675 1.5 m Female Straight PVC, black RAL 9005
1544976 1.5 m Female Straight PVC, black RAL 9005
1693539 1.5 m Female Angled PVC, black RAL 9005
1446333 10 m Female Straight PVC, black RAL 9005
1415727 1.5 m Female Straight PVC, black RAL 9005
1414452 10 m Female Straight PVC, black RAL 9005
1554872 1.5 m Female Straight PVC, black RAL 9005
← Scroll horizontally to view more →

PVC M12 Cable Features

All Phoenix Contact PVC M12 cables feature:

  • Black RAL 9005 PVC sheath
  • A-coded M12 connectors
  • Available in both straight and angled orientations
  • Multiple length options including 1.5m and 10m
  • Standard protection rating of IP65/IP67
  • Suitable for applications where flexibility and chemical resistance requirements are moderate
  • Economical choice for standard industrial environments
  • Operating temperature range: -25°C to 70°C

PUR (Polyurethane)

phoenix contact PUR (Polyurethane) m12 cables

Best for: Dynamic, abrasive, oily, and outdoor environments

Advantages:

  • Outstanding flexibility with small bend radius, perfect for M12 Cables in robotic applications
  • Superior resistance to abrasion, tearing, oils, and chemicals
  • Excellent weather and UV resistance for outdoor installations
  • Halogen-free composition for environmentally conscious applications

Limitations:

  • Higher cost compared to PVC options
  • Slightly lower heat resistance than some specialized materials

Typical Applications:

  • Robotic arm connections
  • Machine tools with exposure to cutting fluids
  • Outdoor installations
  • Mobile equipment
  • Applications with continuous movement

Phoenix Contact PUR Halogen-Free M12 Cables

Browse some of our Phoenix Contact PUR halogen-free M12 cables, designed for maximum durability and reliability in demanding industrial environments.

Part Number Positions Cable Length Connector Type
166812445MStraight Female
1683002410MStraight Female
166984855MStraight Female
1683374510MStraight Female
152036985MStraight Female
1520372810MStraight Female
166824745MAngled Female
1681389410MAngled Female
166987755MAngled Female
1694541510MAngled Female
152264285MAngled Female
1522655810MAngled Female
← Scroll horizontally to view more →

All cables feature:

  • 100% electrically tested reliability
  • PUR halogen-free construction for industrial durability
  • Next-day shipping on in-stock items
  • Full compatibility with industry-standard M12 connectors

Key Benefits of Our PUR Halogen-Free M12 Cables

  • Extended Lifespan: Highly resistant to abrasion, chemicals, oils, and UV radiation
  • Operational Versatility: Maintains flexibility in temperatures from -40°C to 80°C
  • Environmental Responsibility: Halogen-free composition eliminates toxic emissions during fires
  • Cost Efficiency: Reduced replacement frequency and downtime compared to standard cables
  • Universal Compatibility: Works seamlessly with all major industrial automation systems

TPE (Thermoplastic Elastomer)

Best for: High-flex, extreme temperature, and environmentally sensitive applications

Advantages:

  • Exceptional flexibility with outstanding flex life (up to 10 million cycles)
  • Superior performance in extreme cold environments (down to -50°C)
  • Excellent resistance to UV radiation, ozone, chemicals, and flame
  • Non-toxic formula ideal for food and pharmaceutical applications

Limitations:

  • Premium price point
  • May be over-specified for basic applications

Typical Applications:

  • Continuous flexing applications
  • Cold storage and freezer environments
  • Food and beverage processing
  • Pharmaceutical manufacturing
  • Applications requiring extended temperature ranges
  • High-pressure washdown areas requiring IP69K-rated cordsets

Conclusion

Selecting the right M12 cable jacket material ensures your installation meets performance, durability, and safety requirements:

  • PVC is best for static, indoor, and budget-conscious applications where standard cables are appropriate
  • PUR excels in harsh, dynamic, and oily environments requiring premium cables for reliability
  • TPE is unmatched for flexibility, cold resistance, and eco-friendliness, especially in IP69K applications

Need help choosing the right M12 cable for your application?
Contact us today — our automation specialists are here to guide you toward the perfect solution for your environment, budget, and performance needs.
