Official DistributorBy Linemaster
SKU
Lektro - Lok
Motion Control Device
Enclosure
NEMA Type 1 • UL ENCLOSURE Type 1 • EN 60529 Degree of Protection IP20
Purpose
Rocker Action Compact Design
Features & Benefits
- Non-skid Base pad
- Both sides can be wired normally open or normally closed
- All wiring connections are made internally with only a single cord being brought out
- Eliminates costly harness assemblies
- Offers real economy
Materials
- Steel Housing
- Black Finish
- Mechanical Interlock-prevents both circuits from being operated at the same time
- Operates on the teeter-totter principle, Pressure on one side opens or closes line, release of pressure returns switch to normal off position, pressure on other side opens or closes circuit, independent of first
Documents
Technical Specifications
| Switch Type | Electrical |
| Actions | Momentary |
| Circuitries | SPDT (Form "C") |
| Housing Colors | Black |
| Housing Materials | Formed Steel |
| Switch Connections | Solder terminal |
| Electrical Ratings | 10A, 125-250 VAC, 1/2 HP 125-250 VAC |
Why Proax for Linemaster L-2-S?
Proax is the authorized distributor of Linemaster L-2-S. Our highly skilled in-house technical team is ready to assist with any technical needs.
Have a question in mind? to help you get the right product as quickly as possible for your project. We're always here to help!
Short Lead Time
Highly Trained Staff
Live Chat
Technical Support
Local Inventory
60+ Years Experience
Additional Information
| Alternate Names | L2S |
| Pack Size | 1 |
