Technical Specifications
| LED color | White |
| Correlated color temperature | 6,100 K typ. |
| Dimensions | W 320 mm x D 70 mm x H 32 mm |
| Input Voltage | 24 VDC (rating), 22.8 to 26.4 VDC (range) |
| Power consumption | 31 W max. |
| Case Material | Aluminum alloy, resin |
| Input connector | M12 (5 pins, plug) |
| Conformed standards | CE, UKCA, RoHS, IEC 62471（Mod risk） |
| Operating temperature and humidity | Temperature: 0 to 40°C, Humidity: 20 to 85%RH (no condensation) |
| Storage temperature and humidity | Temperature: -20 to 60°C, Humidity: 20 to 85%RH (no condensation) |
| Cooling Method | Natural air cooling |
| Weight | 500 g max. |
| Accessories | User Manual |
| Caution | * The power supply for daisy-chained Light Units must provide sufficient output for all of the Light Units. When the Light Units are used in overdrive mode, the power supply must provide 6 A or more for each Light Unit. |
Why Proax for CCS LDLB-300SW-N?
Proax is the authorized distributor of CCS LDLB-300SW-N. Our highly skilled in-house technical team is ready to assist with any technical needs.
Have a question in mind? to help you get the right product as quickly as possible for your project. We're always here to help!
Short Lead Time
Highly Trained Staff
Live Chat
Technical Support
Local Inventory
60+ Years Experience
Additional Information
| Alternate Names | LDLB300SWN |
| Pack Size | 1 |
Recommended
This Light Unit emits red light and measures 320 x 70 x 32 mm (width x depth x height).The light-emitting surface measures 300 x 24 mm.
