Name: LS35M76D11-S
Brand: ABB
SKU: ABBLS35M76D11S
Price: 95.9400 CAD
Availability: BackOrder

All Switches Safety Sensors, Switches and Locks

Official Distributor

By ABB

SKU

MPN

1SBV033776R1411

Weight

0.184 kg

LS35M76D11-S is a 30 mm wide, standard Safety Limit Switch made of zinc alloy material (Zamak), with 2 mounting holes at the top, 1 1/2'' NPT cable entry on the bottom, rotary stainless steel actuator and 1 N.O + 1 N.C slow action (Zb type), overlapping (late closing) contacts

Documents

Datasheet

Technical Specifications

Dimensions

Product Net Width	30 mm
Product Net Height	80 mm
Product Net Depth / Length	59 mm
Product Net Weight	0.184 kg

Technical

B10d Value	Operations 30 Millions
Conventional Free-air Thermal Current (I_th)	acc. to IEC 60947-5-1, Θ = 40 °C 10 A
Degree of Protection	acc. to IEC 60529 IP66
Maximum Electrical Switching Frequency	(AC-15) 3600 cycles per hour
Maximum Electrical Switching Frequency	(DC-13) 3600 cycles per hour
Mechanical Durability	0 cycle
Pilot Duty UL/CSA	A600
Pilot Duty UL/CSA	Q600
Rated Impulse Withstand Voltage (U_imp)	6 kV
Rated Operational Current AC-15 (I_e)	(230 V AC) 3.1 A
Rated Operational Current AC-15 (I_e)	(400 V) NC 4
Rated Operational Current AC-15 (I_e)	(24 V) 10 A
Rated Operational Current AC-15 (I_e)	(130 V) 5.5 A
Rated Operational Current AC-15 (I_e)	(240 V) 3 A
Rated Insulation Voltage (U_i)	acc. to IEC 60947-5-1 and VDE 0110 (Gr. C) 400 V
Rated Insulation Voltage (U_i)	acc. to UL/CSA 600 V
Rated Operational Current DC-13 (I_e)	(24 V) 6 A
Rated Operational Current DC-13 (I_e)	(110 V) 0.6 A
Rated Operational Current DC-13 (I_e)	(125 V) 0.55 A
Rated Operational Current DC-13 (I_e)	(250 V) 0.4 A
Short-Circuit Protective Devices	gG Type Fuses 10 A
