The illustration shows a version for two pluggable digital I/O modules
5521322
Official DistributorSKU
PHX5521322
MPN
FLKM 4-I/O-G4
Weight
0.11 kg
This product is Not Cancellable/Not Returnable
Series FLKM
FLKM 4-I/O-G4 - Optocoupler module
VARIOFACE 4-channel module for solid state relays
- Modules accept Opto 22 G4 or Grayhill G5 solid state relays
- Solid-state relay includes fuse and status indicator
- Can be fitted with solid-state relays or I/O modules
Technical Specifications
Dimensions
| Width | 67.5 mm |
| Height | 77 mm |
| Depth | 42 mm |
Ambient conditions
| Ambient Temperature (Operation) | -20 °C ... 55 °C |
| Ambient temperature (storage/transport) | -20 °C ... 70 °C |
Input data
| Typical input current at UN | 30 mA (Optocoupler dependent) |
Output data
| Limiting Continuous Current | 4 A |
| Error detection (line break / short-circuit) | no |
General
| No. of channels | 4 |
| Compatible components | Digital I/O modules |
| With components | no |
| Mounting Position | any |
| Assembly instructions | in rows with zero spacing |
| Housing insulation material | PVC, side panel PA non-reinforced, |
Connection data
| Connection name | Input |
| Connection Method | Screw connection |
| Stripping length | 7 mm |
| Screw thread | M3 |
| Number of Connections | 1 |
| Conductor cross section solid | 0.14 mm² ... 2.5 mm² |
| Conductor cross section flexible | 0.14 mm² ... 1.5 mm² |
| Conductor cross section AWG | 24 ... 14 |
Environmental Product Compliance
| REACh SVHC | Lead 7439-92-1 |
| China RoHS | Environmentally Friendly Use Period = 50 years |
| China RoHS | For details about hazardous substances go to tab “Downloads”, Category “Manufacturer's declaration” |
Why Proax for Phoenix Contact 5521322?
Proax is an authorized distributor of Phoenix Contact 5521322 and one of Phoenix Contact's largest distributors in North America. Our highly skilled in-house technical team is ready to assist with any technical needs.
Have a question in mind? to help you get the right product as quickly as possible for your project. We're always here to help!
Short Lead Time
Highly Trained Staff
Live Chat
Technical Support
Local Inventory
60+ Years Experience
Additional Information
| Pack Size | 1 |
