The figure shows a 5-pos. version of the product in gray
Official DistributorSKU
MPN
BCDH-500H- 4 GN
Weight
0.005 kg
This product is Not Cancellable/Not Returnable
Series BCDH
BCDH-500H- 4 GN - PCB connectors
Technical Specifications
Product properties
| Type | Standard |
| Number of Positions | 4 |
| Pitch | 5 mm |
| Mounting flange | without |
| Pin layout | Linear pinning |
Electrical properties
| Maximum Load Current | 10 A |
| Rated voltage (II/2) | 400 V |
| Rated voltage (III/2) | 320 V |
| Rated surge voltage (II/2) | 4 kV |
| Rated surge voltage (III/2) | 4 kV |
| Rated surge voltage (III/3) | 4 kV |
Connection data
| Maximum Load Current | 10 A |
Dimensions
| Length of the solder pin | 3.2 mm |
| Length | 22.1 mm |
| Length of the solder pin | 3.2 mm |
| Hole diameter | 1.4 mm |
| Pitch | 5 mm |
Material specifications
| Flammability rating according to UL 94 | V0 |
| Insulating material group | I |
| Insulating material | PA |
| Contact surface | Tin Sn |
Mechanical data
| Open side panel | Yes |
Standards and Regulations
| Connection in acc. with standard | EN-VDE |
Mounting
| Mounting Type | Wave soldering |
| Pin layout | Linear pinning |
Packaging specifications
| Type of packaging | packed in cardboard |
Why Proax for Phoenix Contact 5443001?
Proax is an authorized distributor of Phoenix Contact 5443001 and one of Phoenix Contact's largest distributors in North America. Our highly skilled in-house technical team is ready to assist with any technical needs.
Have a question in mind? to help you get the right product as quickly as possible for your project. We're always here to help!
Short Lead Time
Highly Trained Staff
Live Chat
Technical Support
Local Inventory
60+ Years Experience
Additional Information
| Pack Size | 100 |
