Official DistributorSKU
MPN
VAL-SQ SE 120-277/480Y-R
Series VAL-SQ-SE
VAL-SQ SE 120-277/480Y-R - Type 2 surge protection replacement module
Replacement module, 120 kA surge protection, 277/480 V AC Wye system
Technical Specifications
Product properties
| Type | Parallel MOV |
General
| Power Systems | 277/480 V Wye |
Connection data
| Connection Method | Screw terminal blocks |
| Tightening torque, min | 4 Nm |
Protective circuit
| Direction of action | 3L-N & N-GND |
| Maximum continuous voltage UC | 320 V |
| Response time tA | < 1 ns |
Ambient conditions
| Ambient Temperature (Operation) | -40 °C ... 60 °C |
| Ambient temperature (storage/transport) | -40 °C ... 85 °C |
| Altitude | 3658 m |
UL specifications
| Short-circuit current rating (SCCR) | 200 kA |
| Maximum Surge Current per Phase | 120 kA |
Why Proax for Phoenix Contact 2804199?
Proax is an authorized distributor of Phoenix Contact 2804199 and one of Phoenix Contact's largest distributors in North America. Our highly skilled in-house technical team is ready to assist with any technical needs.
Have a question in mind? to help you get the right product as quickly as possible for your project. We're always here to help!
Short Lead Time
Highly Trained Staff
Live Chat
Technical Support
Local Inventory
60+ Years Experience
Additional Information
| Pack Size | 1 |
