2715982
Official DistributorSKU
PHX2715982
MPN
IAK 16
Weight
0.013 kg
IAK 16 - Branch terminal
Branch terminal, nominal current: 57 A, connection method: Screw connection, cross section: 0.5 mm2 - 16 mm2, color: gray
Technical Specifications
Product properties
| Number of rows | 1 |
Electrical properties
| Maximum Load Current | 76 A |
| Maximum power dissipation for nominal condition | 0 W |
| Nominal current IN | 57 A |
Connection data
| Maximum Load Current | 76 A |
| Screw thread | M4 |
| Conductor cross section rigid | 0.5 mm² ... 16 mm² |
| Cross section AWG | 20 ... 6 (converted acc. to IEC) |
| Conductor cross section flexible | 0.5 mm² ... 10 mm² |
| Conductor cross section, flexible [AWG] | 20 ... 8 (converted acc. to IEC) |
| Conductor cross-section flexible (ferrule without plastic sleeve) | 0.5 mm² ... 16 mm² |
| Flexible conductor cross section (ferrule with plastic sleeve) | 0.5 mm² ... 10 mm² |
| 2 conductors with same cross section, solid | 0.5 mm² ... 10 mm² |
| 2 conductors with same cross section, flexible | 0.5 mm² ... 10 mm² |
| 2 conductors with same cross section, flexible, with ferrule without plastic sleeve | 0.5 mm² ... 10 mm² |
| 2 conductors with the same cross section, flexible, with TWIN ferrule with plastic sleeve | 0.5 mm² ... 10 mm² |
| Nominal Current | 57 A |
| Maximum Load Current | 76 A (with 16 mm² conductor cross section) |
Dimensions
| Width | 7.7 mm |
| Height | 22.9 mm |
| Depth | 28 mm |
| Length | 22.9 mm |
Material specifications
| Color | gray |
Why Proax for Phoenix Contact 2715982?
Proax is an authorized distributor of Phoenix Contact 2715982 and one of Phoenix Contact's largest distributors in North America. Our highly skilled in-house technical team is ready to assist with any technical needs.
Have a question in mind? to help you get the right product as quickly as possible for your project. We're always here to help!
Short Lead Time
Highly Trained Staff
Live Chat
Technical Support
Local Inventory
60+ Years Experience
Additional Information
| Pack Size | 50 |
