1914823
Official DistributorSKU
PHX1914823
MPN
HCC 4-CLIP
Weight
0 kg
Series HCC
HCC 4-CLIP - Safety latch
Locking clip for engagement catches
Technical Specifications
Product properties
| Product family | Accessories |
| Number of Positions | 1 |
| Pitch | 0 mm |
Dimensions
| Pitch | 0 mm |
Material specifications
| Contact surface | Tin Sn |
Ambient conditions
| Ambient Temperature (Operation) | -60 °C ... 105 °C (max. short-term operating temperature RTI Elec.) |
| Ambient temperature (storage/transport) | -25 °C ... 60 °C (for a short time, not exceeding 24 h, -60 °C to +70 °C) |
| Ambient temperature (assembly) | -5 °C ... 70 °C |
| Ambient temperature (actuation) | -5 °C ... 70 °C |
| Permissible humidity (storage/transport) | 30 % ... 70 % |
Why Proax for Phoenix Contact 1914823?
Proax is an authorized distributor of Phoenix Contact 1914823 and one of Phoenix Contact's largest distributors in North America. Our highly skilled in-house technical team is ready to assist with any technical needs.
Have a question in mind? to help you get the right product as quickly as possible for your project. We're always here to help!
Short Lead Time
Highly Trained Staff
Live Chat
Technical Support
Local Inventory
60+ Years Experience
Additional Information
| Pack Size | 100 |
