ABW4500SLCSB2120-1BK
Official DistributorBy ABB
SKU
ABBABW4500SLCSB21201BK
MPN
7TAA261300R0137
Weight
1 kg
Aluminum Quick Disconnect Transformer Connectors - ABW In-line bar, cable range 6-500, length 6-1/16 inch, stud size 1, outlets 4, with Street Light Outlet Option, Oxide Inhibitor, with Street Light tap, with Drop-On Insulating Boot for Transformer Spade Connector - Length 8 3/4 inches X Width 2 1/2 inches X Height 5 1/5 inches, Color Black
Technical Specifications
Additional Information
| Application | Stud Mount Transformer Connector |
| Brand / Label | Homac |
| Connection Type | Mechanical |
| Effective Date | 20080619 |
| Insulation Material | Insulating Boot |
| Material | Aluminum |
Additional Information
| Number of Conductors | 4 |
| Product Name | Terminals, electrical splices and electr ical couplings; wafer probers |
| Product type | Quick-Disconnect Transformer Connector |
| Special Functions | In-Line Bar Series. Dual Rated for Aluminum and Copper Conductors. High Strength Aluminum Alloy maintains constant bolting pressure on Conductors. Quick Disconnectability for easy removal from transformer secondary studs. Ball-bottom screws ensure maximum conductor contact pressure and break up interstrand oxides. |
| Standards | ANSI C119.4 |
Why Proax for ABB ABW4500SLCSB2120-1BK?
Proax is an authorized distributor of ABB ABW4500SLCSB2120-1BK and one of ABB's largest distributors in North America. Our highly skilled in-house technical team is ready to assist with any technical needs.
Have a question in mind? to help you get the right product as quickly as possible for your project. We're always here to help!
Short Lead Time
Highly Trained Staff
Live Chat
Technical Support
Local Inventory
60+ Years Experience
Additional Information
| Alternate Names | ABW4500SLCSB21201BK |
| Pack Size | 50 |
