Official DistributorBy ABB
SKU
Weight
1 kg
Exit Combination Unit, MR16 LED, 6V-4W, Colour: factory white, self-powered, 120/277VAC, Battery Type: lead-calcium, Voltage DC: 6V, Battery Wattage: 28W, two lamps, Lamp Type: MR16 LED, Lamp Voltage: 6V, Lamp Wattage: 4W, Head Style: standard, Legend Colour: red, Battery Run Time (Minimum): 30 minutes
Technical Specifications
Additional Information
| Product Main Type | Emergency Lighting |
| Application | Commercial, Industrial |
| Product type | Exit Combination Unit |
Dimensions
| Product Net Height | 12-1/4 in |
| Product Net Depth / Length | 13-3/8 in |
| Product Net Width | 4-5/8 in |
| Product Net Weight | 9.00081 lb, 4.082 kg |
Technical
| Mounting Type | Universal |
| Text Color | Red |
| Lamp Type | MR16 LED |
| Number of Lamps | 2 |
| Number of Batteries | 0 |
| Color | Factory white |
| Material | Housing/Faceplate: Steel |
| Power Consumption (@Pcons) | 28 W |
| Power Watt | 4 W |
| Voltage Rating | 120/347 V AC, 6 V DC |
| Size | 13-1/2 Inches Height x 13-3/8 Inches Width |
Environmental
| RoHS Status | No declaration needed |
Why Proax for ABB 8LMCE2LD1ZC?
Proax is an authorized distributor of ABB 8LMCE2LD1ZC and one of ABB's largest distributors in North America. Our highly skilled in-house technical team is ready to assist with any technical needs.
Have a question in mind? to help you get the right product as quickly as possible for your project. We're always here to help!
Short Lead Time
Highly Trained Staff
Live Chat
Technical Support
Local Inventory
60+ Years Experience
Additional Information
| Pack Size | 1 |
