IPSZ3A11
Official DistributorBy ABB
SKU
ABBIPSZ3A11
Weight
1 kg
IPSZ3A11 is a Covered Foot Switch with grey base and half red ABS cover. The pedal movement is maintained and locked in activated (low) position and the switch is equipped with 1 Pg16 cable entry and 1 N.O + 1 N.C snap action (Za type) contacts.
Technical Specifications
Dimensions
| Product Net Width | 140 mm |
| Product Net Height | 85 mm |
| Product Net Depth / Length | 280 mm |
| Product Net Weight | 0.95 kg |
Technical
| Action Type of the Contact Element (acc. to IEC 60947-5-1) | Snap action contacts |
| Actuation Torque | acc. to IEC 60947-5-1 Min. 0.25 N·m |
| Climatic Withstand | according to IEC 68-2-3 and salty mist according to IEC 68-2-11 |
| Conventional Free-air Thermal Current (Ith) | acc. to IEC 60947-5-1, q = 40 °C 10 A |
| Connecting Capacity | Bar AWG 20 ... AWG 14 mm², Bar 0.5 ... 2.5 mm² |
| Contact Element Form (acc. to IEC 60947-5-1) | Za |
| Connecting Terminals (delivered in open position) | M3.5 (+,-) screw Phillips head n░1 with captive cable gland |
| Degree of Protection | acc. to IEC 60529 IP65 |
| Electrical Shock Protection acc. to IEC 536 | Double insulation - Class II |
| Flammability According to UL94 | V-0 |
| Mechanical Durability | 30 million |
| Number of Auxiliary Contacts NC | 1 |
| Number of Auxiliary Contacts NO | 1 |
| Number and Type of Bottom Cable Glands | Pg 16 Cable Gland |
| Pilot Duty UL/CSA | A600, Q600 |
| Positive Opening Operation of NC Contact(s) | Yes |
| Rated Impulse Withstand Voltage (Uimp) | 6 kV |
| Rated Operational Current AC-15 (Ie) | (400 V) NC 4, (24 V) 10 A, (130 V) 5.5 A |
| Rated Frequency (f) | Supply Circuit 50 / 60 Hz |
| Rated Insulation Voltage (Ui) | acc. to IEC 60947-5-1 and VDE 0110 (Gr. C) 690 V, acc. to UL/CSA 600 V |
| Rated Operational Current DC-13 (Ie) | (24 V) 6 A, (110 V) 0.6 / 66 A, (125 V) 0.55 A, (250 V) 0.4 A |
| Resistance Between Contacts | 25 E45 |
| Short-Circuit Protective Devices | gG Type Fuses 10 A |
| Terminal Marking | according to EN 50013 |
Environmental
| Ambient Air Temperature | Operation -10 ... +70 °C, Storage -30 ... +80 °C |
| Resistance to Shock acc. to IEC 60068-2-27 | Half-sine Pulse for 11 ms, No Change in Contact Position 50 m/s² |
| Resistance to Vibrations acc. to IEC 60068-2-6 | 25g (10 to 500 Hz) no change in position of contacts greater than 100 µs |
| RoHS Status | Following EU Directive 2011/65/EU |
Why Proax for ABB IPSZ3A11?
Proax is an authorized distributor of ABB IPSZ3A11 and one of ABB's largest distributors in North America. Our highly skilled in-house technical team is ready to assist with any technical needs.
Have a question in mind? to help you get the right product as quickly as possible for your project. We're always here to help!
Short Lead Time
Highly Trained Staff
Live Chat
Technical Support
Local Inventory
60+ Years Experience
Additional Information
| Pack Size | 2 |
