Official DistributorBy ABB
SKU
MPN
1SBV010111R1211
Weight
0.073 kg
LS31P11B11 is a 30 mm wide, standard Limit Switch made of fiber-glass reinforced UL-V0 material, with 2 mounting holes at the top, 1 Pg11 cable entry on the bottom, plain steel plunger actuator and 1 N.O + 1 N.C snap action (Zb type) contacts
Technical Specifications
Dimensions
| Product Net Width | 30 mm |
| Product Net Height | 73 mm |
| Product Net Depth / Length | 30 mm |
| Product Net Weight | 0.063 kg |
Technical
| Action Type of the Contact Element (acc. to IEC 60947-5-1) | Snap action contacts |
| Actuating force | Minimum Force acc. to IEC 60947-5-1 9 N |
| Actuation Speed | acc. to IEC 60947-5-1 Max. 0.5 m/s |
| Actuation Speed | acc. to IEC 60947-5-1 Min. 0 m/s |
| Actuator Type | plain steel plunger |
| Angular Head Adjustment | adjustable head every 90° |
| Angular Lever Adjustment | none |
| B10d Value | Operations 30 Millions |
| Climatic Withstand | according to IEC 68-2-3 and salty mist according to IEC 68-2-11 |
| Conventional Free-air Thermal Current (Ith) | acc. to IEC 60947-5-1, Θ = 40 °C 10 A |
| Connecting Capacity | Bar AWG 20 ... AWG 14 mm² |
| Connecting Capacity | Bar 0.5 ... 2.5 mm² |
| Consistency (Measured over 1 Million Operations) | 0.1 mm |
| Contact Element Form (acc. to IEC 60947-5-1) | Zb |
| Connecting Terminals (delivered in open position) | M3.5 (+,-) pozidriv 2 screw with cable clamp |
| Degree of Protection | acc. to IEC 60529 IP65 |
| Electrical Shock Protection acc. to IEC 536 | Double insulation - Class II |
| Flammability According to UL94 | V-0 |
| Maximum Electrical Switching Frequency | 3600 cycles per hour |
| Maximum Electrical Switching Frequency | (AC-15) 3600 cycles per hour |
| Maximum Electrical Switching Frequency | (DC-13) 3600 cycles per hour |
| Mechanical Durability | 0 cycle |
| Mounting by Screws (not supplied) | 2 x M4 screws |
| Movement to be Detected | on end |
| Number of Auxiliary Contacts NC | 1 |
| Number of Auxiliary Contacts NO | 1 |
| Number and Type of Bottom Cable Glands | Pg 11 cable gland |
| Operating Head Shape | B shape acc. EN 50047 |
| Pilot Duty UL/CSA | A600 |
| Pilot Duty UL/CSA | Q600 |
| Positive Opening Operation Force (Direct Opening Action) | Minimum Force acc. to IEC 60947-5-1 44 NEW |
| Positive Opening Operation of NC Contact(s) | Yes |
| Rated Impulse Withstand Voltage (Uimp) | 6 kV |
| Rated Operational Current AC-15 (Ie) | (230 V AC) 3.1 A |
| Rated Operational Current AC-15 (Ie) | (400 V) NC 4 |
| Rated Operational Current AC-15 (Ie) | (24 V) 10 A |
| Rated Operational Current AC-15 (Ie) | (130 V) 5.5 A |
| Rated Operational Current AC-15 (Ie) | (240 V) 3 A |
| Rated Frequency (f) | Supply Circuit 50 / 60 Hz |
| Rated Insulation Voltage (Ui) | acc. to IEC 60947-5-1 and VDE 0110 (Gr. C) 500 V |
| Rated Insulation Voltage (Ui) | acc. to UL/CSA 600 V |
| Rated Operational Current DC-13 (Ie) | (24 V) 6 A |
| Rated Operational Current DC-13 (Ie) | (110 V) 0.6 A |
| Rated Operational Current DC-13 (Ie) | (125 V) 0.55 A |
| Rated Operational Current DC-13 (Ie) | (250 V) 0.4 A |
| Resistance Between Contacts | 25 E45 |
| Short-Circuit Protective Devices | gG Type Fuses 10 A |
| Terminal Marking | according to EN 50013 |
Why Proax for ABB LS31P11B11?
Proax is an authorized distributor of ABB LS31P11B11 and one of ABB's largest distributors in North America. Our highly skilled in-house technical team is ready to assist with any technical needs.
Have a question in mind? to help you get the right product as quickly as possible for your project. We're always here to help!
Short Lead Time
Highly Trained Staff
Live Chat
Technical Support
Local Inventory
60+ Years Experience
Additional Information
| Pack Size | 10 |
