Official DistributorBy Omron
SKU
Series D4N-R Safety Limit Switch
Limit switch, One-way roller arm lever (vertical), 1NC/1NO (slow-action), 1NC/1NO (slow-action), Pg13.5 (1-conduit), manual reset feature
Documents
D4N-R Safety Limit Switch
Safety limit switch with manual pull-reset for use in overtravel detection of elevators, moving tables, and other similar applications
Save time during installation and troubleshooting when using a safety limit switch as part of your safety application. The D4N-R series offers manual reset, plastic housing, M20 and M12 connector options, and a wide range of actuators types to make it easier to meet your machine safety requirements.
- Direct opening mechanism
- Various actuators
- Pull-reset switches
- Gold-plated contacts for handling micro loads
- Metric conduit types available
Overview
- A series of pull-reset models now available
- Lineup includes three contact models with 2NC/1NO and 3NC contact forms in addition to the previous contact forms 1NC/1NO and 2NC.
- M12-connector models are available, saving on labor and simplifying replacement.
- Standardized gold-clad contacts provide high contact reliability. Can be used with both standard loads and microloads.
- Conforms to EN115, EN81-1 and EN81-2.
- Certified standards: UL, EN (TÜV), and CCC
Contact Form
Technical Specifications
| Conduit Size | Pg13.5 (1-conduit) |
| Contact | 1NC/1NO (slow-action) |
| Actuator | One-way roller arm lever (vertical) |
| Max Actuation Speed (Operating Speed?) | 1 mm/s to 0.5 m/s |
| Max Actuation Frequency | 30 operations/min |
Why Proax for Omron D4N-1A72R?
Proax is an authorized distributor of Omron D4N-1A72R. We are Omron’s largest distributor in Canada. Our highly skilled in-house technical team is ready to assist with any technical needs.
Have a question in mind? to help you get the right product as quickly as possible for your project. We're always here to help!
Short Lead Time
Highly Trained Staff
Live Chat
Technical Support
Local Inventory
60+ Years Experience
Additional Information
| Alternate Names | D4N1A72R |
| Pack Size | 1 |
