Technical Specifications
Technical
| Rated Operational Voltage | 690 V AC |
| Rated Operational Voltage | 1500 V DC |
| Frequency (f) | Rated Current 50 Hz |
| Power Consumption (@Pcons) | At Rated Load 0.27 W |
| Accuracy | 0.5% FS |
| Measuring Range | 0.1…40 A |
| Mounting Type | Surface Mounting |
| Sensor Type | Solid-core (18 mm) |
| Output | Other |
Dimensions
| Product Net Width | 17.4 mm |
| Product Net Height | 26.5 mm |
| Product Net Depth / Length | 41 mm |
| Product Net Weight | 12 g |
Installation
| Instructions and Manuals | 9AKK106930A6241 |
Why Proax for ABB CMS-101PS?
Proax is an authorized distributor of ABB CMS-101PS and one of ABB's largest distributors in North America. Our highly skilled in-house technical team is ready to assist with any technical needs.
Have a question in mind? to help you get the right product as quickly as possible for your project. We're always here to help!
Short Lead Time
Highly Trained Staff
Live Chat
Technical Support
Local Inventory
60+ Years Experience
Additional Information
| Alternate Names | CMS101PS |
| Pack Size | 1 |
