CA5-22N
Official DistributorBy ABB
SKU
ABBCA522N
MPN
1SBN010040R1222
Weight
0.06 kg
CA5-22N is a 4-pole front mounted auxiliary contact block equipped with screw terminals. CA5-..M version offers terminal assortment matching the marking of 4-pole N contactor relays. CA5-22N is available with 2 N.O. and 2 N.C. instantaneous contacts for standard industrial environments.
Technical Specifications
Supplier Information - CHABB001
| Country or Territory of Origin | Switzerland |
| Lead Time | 90 day |
| Made to Order | No |
| Product Sales Status | Active |
| Quote Only | No |
| Stocked At Warehouses | CHABB001EXPU |
| Warranty Return | Product under warranty must be returned |
Dimensions
| Product Net Width | 43 mm |
| Product Net Depth / Length | 39 mm |
| Product Net Height | 47 mm |
| Product Net Weight | 0.06 kg |
Technical
| Number of Auxiliary Contacts NO | 2 |
| Number of Auxiliary Contacts NC | 2 |
| Number of Poles | 4P |
| Rated Operational Voltage | Auxiliary Circuit 690 V |
| Rated Frequency (f) | Auxiliary Circuit 50 / 60 Hz |
| Rated Operational Current AC-15 (Ie) | (500 V) 2 A |
| Rated Operational Current AC-15 (Ie) | (690 V) 2 A |
| Rated Operational Current AC-15 (Ie) | (24 / 127 V) 6 A |
| Rated Operational Current AC-15 (Ie) | (220 / 240 V) 4 A |
| Rated Operational Current AC-15 (Ie) | (380 / 400 V) 3 A |
| Rated Operational Current DC-13 (Ie) | (24 V) 6 A / 144 W |
| Rated Operational Current DC-13 (Ie) | (48 V) 2.8 A / 134 W |
| Rated Operational Current DC-13 (Ie) | (72 V) 1 A / 72 W |
| Rated Operational Current DC-13 (Ie) | (110 V) 0.55 A / 60 W |
| Rated Operational Current DC-13 (Ie) | (125 V) 0.55 A / 69 W |
| Rated Operational Current DC-13 (Ie) | (220 V) 0.30 A / 66 W |
| Rated Operational Current DC-13 (Ie) | (250 V) 0.3 / 75 W |
| Short-Circuit Protective Devices | Auxiliary Circuit - gG Type Fuses 10 A |
| Rated Short-time Withstand Current Low Voltage (Icw) | for 0.1 s 140 A |
| Rated Short-time Withstand Current Low Voltage (Icw) | for 1 s 100 A |
| Rated Insulation Voltage (Ui) | acc. to IEC 60947-5-1 690 V |
| Rated Insulation Voltage (Ui) | acc. to UL/CSA 600 V |
| Maximum Electrical Switching Frequency | 1200 cycles per hour |
| Mechanical Durability | 10 million |
| Maximum Mechanical Switching Frequency | 3600 cycles per hour |
| Minimum switching capacity | N 17 / 5 VLT4K |
| Power Loss | at Rated Operating Conditions per Pole 0.1 W |
| Degree of Protection | acc. to IEC 60529, IEC 60947-1, EN 60529 Auxiliary Terminals IP20 |
| Terminal Type | Screw Terminals |
| Suitable for | N22E |
| Suitable for | N31E |
| Suitable for | N40E |
| Suitable for | NL22E |
| Suitable for | NL31E |
| Suitable for | NL40E |
| Suitable for | TNL22E |
| Suitable for | TNL31E |
| Suitable for | TNL40E |
| Product Name | Auxiliary Contact Block |
| Remarks | 100 |
