Technical Specifications
| TYP2 | Surface |
| Cover | ESG |
| Cover Type | Diffuse |
| Connection | Connector |
| Connection Size | M12 |
| Poles | 5 |
| Coding | A-coded |
| DURCHSCHL | Yes |
| Housing Material | Aluminium |
| Mounting | Turnable |
| Light beam angle | 100 |
| Light length | 140 |
| Prod. Length | 240 |
| Prod. Width | 40 |
| Prod. Hight | 42 |
| Packaging length | 473 |
| Packaging width | 79 |
| Packaging hight | 80 |
| Colour spec. | W |
| Light Colour | 5700 |
| CRI | 80 |
| EMAX | 133 |
| Lumen white | 339 |
| Lumen red | 0 |
| Lumen green | 0 |
| Lumen blue | 0 |
| Power White | 3.3 |
| Power green | 0 |
| Power red | 0 |
| Power blue | 0 |
| Total power | 3.3 |
| Voltage | 24 |
| Voltage type | VDC |
| Dimmable | extern PWM |
| MINUMTEMP | -20 |
| MAXUMTEMP | +45 |
| Lifespan | 60000 |
| CE | Yes |
| UKCA | Yes |
| UL | Yes |
| EFILENR | E494369 |
| Protection class | 3 |
| IP-rating | IP67 |
