MPDB63133
Official DistributorBy Mersen
Mersen MPDB63133 Open-Style Power Distribution Block, UL 1953 Rated, 1000V, 135A, Aluminum, 3-Pole
The Mersen MPDB63133 is an open-style power distribution block designed for safe and efficient power splitting in industrial control panels and electrical enclosures. It provides fixed junction tap-off points while meeting UL 508A and NEC® spacing requirements for feeder and branch circuits.
Constructed with tin-plated aluminum conductors, this PDB supports high current applications and ensures long-term reliability in demanding environments. UL and CSA approved for use in industrial power distribution systems.
Rated Voltage: 1000V AC / DC
Ampacity (Aluminum): 135A (175A frame)
Poles: 3
Primary Input: 1 opening, 2/0 – #14 AWG
Secondary Outputs: Up to 4 openings, #4 – #14 AWG
Material: Tin-plated aluminum
Design: Open-style, box-to-box mounting
Compliance: UL 1953, UL 508A, CSA, NEC®
EAN / UPC: 782001449421
Frequency: 50/60 Hz
