Official DistributorBy Mersen
SKU
Series GDG - Time-Delay
Miniature fuse GDG - Time-Delay 250VAC 10A Size 5x20 Ferrule
Documents
GDG - Time-Delay
250V, Time Delay, Glass, 5mm x 20mm
Features
- Glass body
- Time-delay
- 5 mm x 20 mm
Applications
- Electronic circuits
Technical Specifications
| Ampere Rating | 10 A |
| Ac - Dc - Ac Dc | AC |
| Rated Voltage Ac Ul | 250 V |
| Product Diameter | 5.1 mm |
| Product Length | 20.1 mm |
| Product Weight | 0.0045 kg |
| Fuse Class | Supplemental |
| Fuse Construction Size | 5x20 |
| Indication System | 0 |
| Speed Characteristic | Time Delay |
| Mounting | Clip |
| Connection Terminal Type | Ferrule |
| Body Insulating Material | Glass |
Why Proax for Mersen GDG10?
Proax is the authorized distributor of Mersen GDG10. Our highly skilled in-house technical team is ready to assist with any technical needs.
Have a question in mind? to help you get the right product as quickly as possible for your project. We're always here to help!
Short Lead Time
Highly Trained Staff
Live Chat
Technical Support
Local Inventory
60+ Years Experience
Additional Information
| Pack Size | 5 |
