Official DistributorBy ABB
SKU
MPN
1SVR405600R5000
Weight
0.014 kg
The CR-P048AC1 pluggable interface relay is suitable for direct mounting on a printed circuit board or use in conjunction with ABB's sockets. This relay operates with a 48 V AC rated control supply voltage and has a 1 c/o (SPDT) output with contacts rated at 250 V / 16 A, enabling the possibility of switching multiple circuits with a single input signal. Coupled with a socket, the compact size of this relay offers possibilities to save space within a control panel. Furthermore, with an IP degree of 67, this relay offers complete protection against ingress of dust and airborne particles & protection against water and liquids, up to and including immersion in up to one meter of water. Standard sockets, logical sockets, pluggable function modules, holder and marker are available as accessories.
Technical Specifications
Dimensions
| Product Net Width | 12.7 mm |
| Product Net Height | 15.7 mm |
| Product Net Depth / Length | 29 mm |
| Product Net Weight | 0.014 kg |
Technical
| Function | Pluggable pcb interface relay CR-P |
| Sub-Function | Relay w/o built in LED |
| Rated Control Supply Voltage (Us) | 48 V AC |
| Rated Operational Voltage | 400 V AC |
| Rated Frequency (f) | 50 / 60 Hz |
| Output | 1 c/o (SPDT) contact |
| Output signal | 250 V / 16 A |
| Terminal Type | Soldering Pins |
| Rated Operational Current AC-12 (Ie) | (230 V) 16 A |
| Rated Operational Current AC-15 (Ie) | (120 V) 3 A |
| Rated Operational Current AC-15 (Ie) | (230 V) 1.5 A |
| Rated Operational Current DC-12 (Ie) | (24 V) 16 A |
| Rated Operational Current DC-13 (Ie) | (24 V) 2.5 A |
| Rated Operational Current DC-13 (Ie) | (250 V) 0.1 A |
| Rated Insulation Voltage (Ui) | 400 V |
| Degree of Protection | IP67 |
| Mounting Position | 1 |
| Standards | IEC/EN 61810-1 |
Technical UL/CSA
| Maximum Operating Voltage UL/CSA | 300 V AC |
| Contact Rating UL/CSA | B300 |
| Pilot Duty UL/CSA | B300 |
| Flammability According to UL94 | V-0 |
Why Proax for ABB CR-P048AC1?
Proax is an authorized distributor of ABB CR-P048AC1 and one of ABB's largest distributors in North America. Our highly skilled in-house technical team is ready to assist with any technical needs.
Have a question in mind? to help you get the right product as quickly as possible for your project. We're always here to help!
Short Lead Time
Highly Trained Staff
Live Chat
Technical Support
Local Inventory
60+ Years Experience
Additional Information
| Alternate Names | CRP048AC1 |
| Pack Size | 10 |
