5501635
Official DistributorBy Rittal
SKU
RIT5501635
Weight
3.7 kg
DK Component shelf, for one 482.6 mm (19") mounting level, pull-out, 2 U, Pre-configured variant including telescopic slides,, moulded handle, flange and locking pins
Supply includes
Component shelves, preassembled
Assembly components
Component Shelf, Pull-Out, 2 U for a 482.6 mm (19") mounting level
This complete kit contains the pre-configured variant that includes telescopic slides, recessed grip, flange and locking pins.
Technical Specifications
Contact surface
| Depth | 300 mm |
| Width | 430 mm |
| Benefits | Simple, tool-free assembly |
| Material | Carbon steel |
| Surface finish | Spray-finished |
| Color | RAL 9005 |
| Load capacity static | 250 N |
| Weight/packaging unit | 3.7 kg |
| Customs tariff number | 73269098 |
| EAN | 4028177679078 |
| ETIM 7.0 | EC002620 |
| ECLASS 8.0 | 27189261 |
