ZL112A-K15MZ-DYL

SMC ZL112A-K15MZ-DYL is a compact multistage vacuum ejector designed to provide efficient vacuum generation for automated handling and pick-and-place applications. Combining a supply valve, release valve, digital vacuum pressure switch, and silencer in a single lightweight unit, it simplifies system design while reducing air consumption and improving energy efficiency.

• Compact multistage vacuum ejector with integrated vacuum pressure switch

• High-efficiency ejector design for reliable vacuum generation

• Supply valve (N.C.) and release valve (N.C.) integrated into one assembly

• Digital vacuum pressure switch with PNP open collector dual outputs and copy function

• 24 VDC operating voltage

• M plug connector with 300 mm lead wire

• Built-in light and surge voltage suppressor for enhanced electrical protection

• Non-locking push-type manual override

• Silencer exhaust for reduced operating noise

• Vacuum port: Ø12 one-touch fitting; Supply port: Ø6 one-touch fitting

• Pressure display and settings in kPa

• 2 m, 5-core connector lead wire included

• Lightweight integrated design for reduced installation space and simplified pneumatic wiring

• Ideal for vacuum gripping, pick-and-place systems, packaging equipment, and automated material handling applications
