Technical Specifications
| Fixing thread | G1/4" |
| Operating pressure max. [bar] | 10 |
| Operating pressure min. [bar] | 1 |
| Operating pressure [bar] | 1 ... 10 |
| Operating temperature [°C] | -10 ... +70 |
| Operating temperature max. [°C] | 70 |
| Operating temperature min. [°C] | -10 |
| Weight [kg] | 0.27 |
| Nominal flow rate A-P1 | 1000 |
| Nominal flow rate B-P2 | 1000 |
| Nominal flow rate P1-A | 650 |
| Nominal flow rate P2-B | 650 |
| Nominal diameter [mm] | 7 |
| Quick Exhaust | No |
| Series | DSV |
| PWIS-free | Yes |
| REACH compliant | Yes |
| RoHS Compliant | Yes |
Why Proax for Zimmer DSV1-4?
Proax is the authorized distributor of Zimmer DSV1-4. Our highly skilled in-house technical team is ready to assist with any technical needs.
Have a question in mind? to help you get the right product as quickly as possible for your project. We're always here to help!
Short Lead Time
Highly Trained Staff
Live Chat
Technical Support
Local Inventory
60+ Years Experience
Additional Information
| Alternate Names | DSV14 |
| Pack Size | 1 |
