Technical Specifications
| Connection Type | Connector / female |
| Version [Type] | Straight/straight |
| No. of contacts | 5 |
| Nr. of wires x diameter [mm²] | 5x0,34 |
| Connection Type | Male / socket |
| Fixing thread | M12-M12 |
| Type of construction | straight / straight |
| Rated voltage [V] | 125 |
| Supply voltage [V DC] | 125 |
| Installation Size | KAG500 |
| Bending radius for fixed routing, min. | 5xØ |
| Bending radius when using a drag chain, min. | 10xØ |
| Coding | A |
| Flame retardant | Yes |
| Weight [kg] | 0.06 |
| Housing Material | PUR |
| Halogen-free | Yes |
| Hydrolysis proof | Yes |
| Cable-Ø [mm] | 4.8 |
| Cable length [m] | 5 |
| Rated voltage cable [V] | 300 |
| Oil resistant | Yes |
| Recyclable | Yes |
| Acid- and alkali resistant | Yes |
| Protection to IEC 60529 | IP67 |
| Current load (at 40°C) [A] | 4 |
| Drag chain-adapted | Yes |
| Maintenance free (max.) | 5 million cycles |
| Series | KAG |
| Silicone free | Yes |
| Temperature range (fixed) [°C] | -40 ... +90 |
| Torsion | +/-180°/m, < 2 million cycles |
| Torsion resistant | Yes |
| UV resistant | Yes |
| Sealing material | FPM/FKM |
| Grip body material | PUR |
| Cable Sheath Material | PUR |
| Contact Material | Metal, CuSn, gold-plated |
| Coupling nut material | Metal, CuZn, nickel-plated |
| Certification | UL /CSA |
| PWIS-free | Yes |
| REACH compliant | Yes |
| RoHS Compliant | Yes |
