4.69 in. (119 mm) Axial Fan Kit
The MDA series features a built-in alarm circuit that the host controller can recognize if the fan speed drops. This is important for noticing quick drops in the cooling capacity of the fan caused by a service life of the fan or by the ingress of a foreign objects.- Alarm Type
- Fan kit features axial flow fan, finger guard, connection wire and mounting screws in a single package.
Technical Specifications
| Fan Type | Axial Flow |
| Frame Size | 4.69 in |
| Thickness | 1 in. |
| Power Supply | 12 VDC |
| Current | 0.63 |
| Function | Low Speed Alarm - Electronic |
| Connection Type | Connector |
| Speed (r/min) | 3000 |
| Max. Air Flow | 95.3 CFM |
| Max. Static Pressure | 0.281 inH2O |
| Noise Level | 46 dB (A) |
| Components | MDA1225-12H (Fan Unit)FG12D (Finger Guard)Connection CableM4 x 40mm (Mounting Screws) |
| Fan Kit | Fan, Finger Guard, Connection Cable, Mounting Screws |
| RoHS Compliant | These products do not contain substances that exceed the regulation values in the RoHS Directive. |
| Safety Standards | UL |
| CE Marking | EMC Directives |
| Insulation resistance | 10 MΩ or more when 250 VDC is applied between the windings and the frame after continuous operation under normal ambient temperature and humidity. |
| Dielectric strength | Sufficient to withstand 500V at 50Hz applied between the windings and the frame for 1 minute after continuous operation under normal ambient temperature and humidity. |
| Temperature Rise | 18ºF (10ºC) or less measured by the thermometer method after the temperature of the case has stabilized after continuous operation under normal ambient temperature and humidity. |
| Thermal Class | UL/CSA Standards: 105 (A), EN Standards: 120 (E) |
| Overheat Protection | Built-in Overheat Protection Circuit |
| Ambient temperature range | 14ºF ~ 140ºF (-10ºC ~ 60ºC) |
| Ambient Humidity | 85% or less (noncondensing) |
| Alarm Type | Electronic |
| Alarm Activation Speed | 2100 ± 400 r/min |
| Output Mode | Open-collector output |
| Output Condition | Normal operation: L level (Internal transistor ON)Alarm output: H level (Internal transistor OFF) |
| Maximum Rating | Maximum Applied Voltage: 30 VDC max.Maximum Inflow Current: 15 mA max. |
| Delay Function | Built-In Starting Delay Time: 10 sec. max. (The alarm function starts monitoring within 10 sec. after the power is turned on.) |
