Technical Specifications
Technical
| Tripping characteristic | Accessory |
| Function | Signal / Auxiliary Contact |
| Suitable for | S280, S280UC |
| Suitable for Product Class | Miniature Circuit Breaker |
| Operational Voltage | Minimum 12 V AC |
| Rated Impulse Withstand Voltage (Uimp) | 4 kV |
| Dielectric Test Voltage | 50/60 Hz, 1 min: 2 kV |
| Mechanical Endurance | 20000 cycle |
| Overvoltage category | III |
| Tightening torque | 2.8 N·m |
| Accessory Type | Auxiliary Contact / Signal Contact |
| Mounting Position | any |
| Accessories Available | No |
| Remarks | screw connection |
| Terminal Type | Screw Terminals |
Environmental
| Ambient Air Temperature | Operation -25 ... +55 °C, Storage -40 ... +70 °C |
| Ambient Air Temperature Compensation | No |
| Pollution degree | 2 |
| Resistance to Vibrations acc. to IEC 60068-2-6 | 5g, 20 cycles at 5 ... 150 ... 5 Hz with load 0.8 In |
| Resistance to Shock acc. to IEC 60068-2-27 | 25g / 2 shocks / 13 ms |
| RoHS Status | Following EU Directive 2011/65/EU |
Dimensions
| Product Net Width | 8.8 mm |
| Product Net Height | 90 mm |
| Product Net Depth / Length | 68 mm |
| Product Net Weight | 0.051 kg |
| Size | 4 modules |
Why Proax for ABB S2-S/H?
Proax is an authorized distributor of ABB S2-S/H and one of ABB's largest distributors in North America. Our highly skilled in-house technical team is ready to assist with any technical needs.
Have a question in mind? to help you get the right product as quickly as possible for your project. We're always here to help!
Short Lead Time
Highly Trained Staff
Live Chat
Technical Support
Local Inventory
60+ Years Experience
Additional Information
| Alternate Names | S2SH |
| Pack Size | 1 |
