9670406
Official DistributorBy Rittal
SKU
RIT9670406
Weight
43.8 kg
This item is ineligible for free shipping due to its size/weight.
SV Modular enclosure, WHD: 400x2000x600 mm, sheet steel
Supply includes
Enclosure frame
Rear panel
Base plates, three-piece
4 eyebolts
Technical Specifications
Dimensions
| Width | 400 mm |
| Height | 2,000 mm |
| Depth | 600 mm |
Surface finish
| Enclosure frame | Dipcoat-primed |
| Rear panel | Dipcoat-primed, powder-coated on the outside, textured paint |
| Base plates | Zinc-plated |
| Material | Carbon steel |
| Color | RAL 7035 |
| Test specification | IEC 61 439-1/-2 |
| Protection category IP to IEC 60 529 | Up to IP 54, depending on the panels |
| Weight/packaging unit | 43.8 kg |
| EAN | 4028177562431 |
| ETIM 7.0 | EC000268 |
| ECLASS 8.0 | 27180101 |
Why Proax for Rittal 9670406?
Proax is an authorized distributor of Rittal 9670406 and one of Rittal's largest distributors in North America. Our highly skilled in-house technical team is ready to assist with any technical needs.
Have a question in mind? to help you get the right product as quickly as possible for your project. We're always here to help!
Short Lead Time
Highly Trained Staff
Live Chat
Technical Support
Local Inventory
60+ Years Experience
Additional Information
| Pack Size | 1 |
