9629000
Official DistributorBy Rittal
SKU
RIT9629000
Weight
0.794 kg
SV Mini-PLS component adaptor, 100 A, 690 V, 3-pole, connection cable 35 mm², WH: 90x160 mm
Technical Specifications
Dimensions
| Width | 90 mm |
| Height | 160 mm |
| Material | Polyamide Fire protection corresponding to UL 94-V0 |
| Color | RAL 9011 |
| Connection cables (AWG) | 35 mm² |
| Rated operating voltage | 690 V, 3~ |
| Rated current max. | 100 A |
| To fit manufacturer (model) | ABB Eaton Schneider Electric Siemens MS451 max. 40 A MS495 MS496 MS497 T1 T2 NZM 1 PKZM4 NS 80 GV3 3RV10 31 3RV1341/42 |
| Weight/packaging unit | 0.794 kg |
| Copper weight (kg per piece) | 0.23 |
| Customs tariff number | 85369095 |
| EAN | 4028177149861 |
| ETIM 7.0 | EC001531 |
| ECLASS 8.0 | 27370304 |
