The illustration can vary depends on the configuration
2913153
Official DistributorSKU
PHX2913153
MPN
PPC 5115 SCHAEFFLER
Weight
4.441 kg
Series PPC
PPC 5115 SCHAEFFLER - Panel PC
Panel PC with touch screen and software keyboard, 38.1 cm (15") display, one slot.
Technical Specifications
Computer data
| Processor | Intel® Pentium® M 1.6 GHz |
| Operating system | without operating system |
| RAM | 1 GB DDR |
| Slots | 1x PCI/ISA shared |
| Optical drive | No CD-ROM |
| Disk drive | No drive |
| Retain card | No retain card |
| System architecture | ads-X module standard |
| Optional keys | 5 additional keys (software keyboard, task change Alt+Tab, right mouse button, brightness, user-specific function) |
| Monitoring | Temperature, status LEDs at the front |
Display
| Display type | 38.1 cm/15" TFT |
| Screen resolution | 1024 x 768 Pixel(s) (XGA) |
| Touch technology | Resistive industrial touch screen |
| Brightness | 250 cd/m², typical (adjustable) |
| MTBF | > 50000 h |
| Graphics Card | IntelⓇ 855 GME |
Electrical properties
| Service life of battery | 3 ... 5 years (typ.) |
| Power consumption | 65 W ((typical)) |
Supply
| Power Supply Unit | 100 ... 240 V AC, 50/60 Hz |
| Power consumption | max. 150 W (65 watts (typical)) |
Digital:
| Input Voltage | 230 V AC (100 ... 240 V AC) |
Interfaces
| Interfaces | COM 1, COM 2, COM 3 (RS-232), 1x LPT, 1x DVI (VGA), 1x PS/2 mouse, 1x PS/2 keyboard, 3x USB |
| Optional interfaces | with front USB |
| Monitor Output | Analog monitor output max. 1280 x 1024 pixels |
| Network | 2 x Ethernet (10/100 Mbps), RJ45 |
Dimensions
| Width | 390 mm |
| Height | 312 mm |
| Depth | 97 mm |
External dimensions
| Width / Height / Depth | 390 mm / 312 mm / 97 mm |
Installation dimensions
| Width / Height / Installation depth | 376 mm / 299 mm / 97 mm (The device must have a 50 mm ventilation area around it) |
Ambient conditions
| Degree of Protection | IP65 (front), IP20 (back) |
| Ambient Temperature (Operation) | 5 °C ... 45 °C |
| Ambient temperature (storage/transport) | -20 °C ... 45 °C |
| Permissible humidity (operation) | 10 % ... 85 % (non-condensing) |
| Permissible humidity (storage/transport) | 10 % ... 85 % (non-condensing) |
| Shock | DIN EN 60068-2-27 |
| Vibration (Operation) | DIN EN 60068-2-6 |
Mounting
| Mounting Type | Installation in front plate |
