1440711
Official DistributorSKU
PHX1440711
MPN
VS-EC-MSDB SH SCO
Weight
0.011 kg
VS-EC-MSDB SH SCO - Device connector front mounting
Device connector front mounting, 4-position, Socket, straight, M12-SPEEDCON, Front mounting, M12 x 1, Solder pins, Alternative product in accordance with RoHS II without Exemption 6c (Pb < 0.1 %) item no.: 1239709
- Easy PCB assembly: one-piece connectors for wave soldering
- For high transmission reliability: optional shield connection to the housing by means of shield contact
- SPEEDCON fast locking system reduces cabling times
Technical Specifications
Mounting
| Mounting Type | Front mounting M12 x 1 With locking nut |
| Assembly instructions | With locking nut |
Product properties
| Number of Positions | 4 |
| Shielded | yes |
Material specifications
| Flammability rating according to UL 94 | V0 |
| Contact Material | Cu alloy |
| Contact surface material | Gold over nickel |
| Material for screw connection | Zinc die-cast, nickel-plated |
Electrical properties
| Nominal voltage UN | 30 V |
| Nominal current IN | 1 A |
| Transmission characteristics (category) | CAT7, for USB 2.0 (480 Mbps) |
Conductor connection
| Connection Method | Solder pins |
Mechanical data
| Insertion/withdrawal cycles | ≥ 100 |
Connection 1
| Head design | Socket |
| Head cable outlet | straight |
| Head thread type | M12 |
| Head locking type | SPEEDCON |
Ambient conditions
| Degree of Protection | IP67 |
| Degree of Protection | IP67 |
| Ambient Temperature (Operation) | -25 °C ... 85 °C (Plug / socket) |
Accessories
Why Proax for Phoenix Contact 1440711?
Proax is an authorized distributor of Phoenix Contact 1440711 and one of Phoenix Contact's largest distributors in North America. Our highly skilled in-house technical team is ready to assist with any technical needs.
Have a question in mind? to help you get the right product as quickly as possible for your project. We're always here to help!
Short Lead Time
Highly Trained Staff
Live Chat
Technical Support
Local Inventory
60+ Years Experience
Additional Information
| Pack Size | 20 |
