Official DistributorBy Omron
SKU
Weight
0.151 kg
Proximity sensor, inductive, shielded, 5 mm, DC, 3-wire, NPN-NO, 2 m cable
TL-W Standard Flat Proximity Sensor
Flat-Pack Inductive Proximity Sensors
The TL-W family offers a wide range of block style inductive sensors for simple mounting on flat surfaces. With sensing distances from 1.5 mm to 20 mm the TL-W is the ideal solution when cylindrical proximity sensors present mounting challenges.
- Front and side facing surface
- Rated IP67 for water washdown
- DC 2-wire and DC 3-wire models
- Sensing distances from 1.5 mm to 20 mm
- Rugged die-cast metal or heat-resistant ABS plastic housing
Technical Specifications
| Size | 10 x 30 x 52 mm |
| Sensing Distance | 5 mm |
| Shielded | Shielded |
| Connection | PVC cable |
| Output | NPN |
| Operation | NO |
| Supply Voltage | 12 to 24 VDC |
| Case Material | Heat-resistant ABS |
| Threaded Length (mm) | Does not apply, rectangular shape |
| Overall length (mm) | Does not apply, rectangular shape |
| Mounting | Mounts to a flat surface with two M4 screws |
Why Proax for Omron TL-W5E1?
Proax is an authorized distributor of Omron TL-W5E1. We are Omron’s largest distributor in Canada. Our highly skilled in-house technical team is ready to assist with any technical needs.
Have a question in mind? to help you get the right product as quickly as possible for your project. We're always here to help!
Short Lead Time
Highly Trained Staff
Live Chat
Technical Support
Local Inventory
60+ Years Experience
Additional Information
| Alternate Names | TLW5E1 |
| Pack Size | 1 |
