ABB XT1NU3070AAA000XXX – XT1 125A Frame, 3-Pole Thermal Magnetic Circuit Breaker (70A)
The ABB XT1NU3070AAA000XXX is a 3-pole molded case circuit breaker from the reliable Tmax XT Series, designed for efficient protection in low-voltage distribution systems. Rated at 70 amps with a 125A frame, it features a fixed thermal-magnetic trip unit for both overload and short-circuit protection. The breaker supports up to 600 V AC (25kA interrupting capacity at 480 V) and comes equipped with both line and load lugs for straightforward installation.
Key Specifications:
Manufacturer: ABB
Series: Tmax XT
Part Number: XT1NU3070AAA000XXX
Frame Size: XT1 (125A Frame)
Rated Current: 70 A
Trip Unit: Fixed Thermal/Magnetic
Poles: 3
Voltage Rating: Up to 600 V AC
Interrupting Capacity: 25 kA @ 480 V
Connection Type: Includes Line and Load Lugs
Why Proax for ABB XT1NU3070AAA000XXX?
Proax is an authorized distributor of ABB XT1NU3070AAA000XXX and one of ABB's largest distributors in North America. Our highly skilled in-house technical team is ready to assist with any technical needs.
Have a question in mind? to help you get the right product as quickly as possible for your project. We're always here to help!
| Pack Size | 1 |
XT1N 125 TMF 70-700 3P F F UL/CSA Tmax Breaker Frame Size XT1N 125 Thermal Magnetic Fixed 70-700 Three-Pole Fixed + Front Flat Terminals Underwriters Laboratory/Canadian Standards Association
