Technical Specifications
| TYP2 | Surface |
| Cover | ESG |
| Cover Type | Diffuse |
| Connection | Connector |
| Connection Size | M8 |
| Poles | 4 |
| Coding | A-coded |
| DURCHSCHL | No |
| Housing Material | Aluminium |
| Mounting | Static |
| Light beam angle | 100 |
| Light length | 85 |
| Prod. Length | 105 |
| Prod. Width | 25 |
| Prod. Hight | 17.5 |
| Packaging length | 368 |
| Packaging width | 70 |
| Packaging hight | 69 |
| Colour spec. | W |
| Light Colour | 5700 |
| CRI | 80 |
| EMAX | 129 |
| Lumen white | 381 |
| Lumen red | 0 |
| Lumen green | 0 |
| Lumen blue | 0 |
| Power White | 3.3 |
| Power green | 0 |
| Power red | 0 |
| Power blue | 0 |
| Total power | 3.3 |
| Voltage | 24 |
| Voltage type | VDC |
| Dimmable | extern PWM |
| MINUMTEMP | -20 |
| MAXUMTEMP | +45 |
| Lifespan | 60000 |
| CE | Yes |
| UKCA | Yes |
| UL | Yes |
| EFILENR | E494369 |
| Protection class | 3 |
| IP-rating | IP67 |
Why Proax for Sangel 15070136?
Proax is the authorized distributor of Sangel 15070136. Our highly skilled in-house technical team is ready to assist with any technical needs.
Have a question in mind? to help you get the right product as quickly as possible for your project. We're always here to help!
Short Lead Time
Highly Trained Staff
Live Chat
Technical Support
Local Inventory
60+ Years Experience
Additional Information
| Pack Size | 1 |
